Application

Can be used as a perimeter security system in:

  • Emergency services and health.
  • Agricultural establishments.
  • Residential and commercial.
  • Schools.
  • Civic and public sectors.
  • Industrial and security applications.
  • Utilities.
  • Construction.

Description

Perimeter security vertical bar railing system manufactured with no welded parts. Each panel uses vertical bar infills, manufactured from hollow tube that is fixed into place on the horizontal rectangular hollow section (RHS) tube.

Features and benefits:

  • Strong and vandal resistant.
  • Concealed connections between panels and posts create clean lines with no visible fixings.
  • Designed with solid joints for each vertical rail.
  • Railings are adjustable.
  • Attractive appearance.
  • Ground level panel termination.
  • Infills are available with square or mitred tops.
  • Flexible, and can cope with changes in terrain.
  • Low carbon emissions during manufacture to provide a sustainable fencing system.

Applications:

Can be used as a perimeter security system in:

  • Emergency services and health.
  • Agricultural establishments.
  • Residential and commercial.
  • Schools.
  • Civic and public sectors.
  • Industrial and security applications.
  • Utilities.
  • Construction.

General information
Specification data - Carbon steel framed vertical section panels
Product Reference

Apex Railing, adjustable raking version

Apex Railing, standard version

Height

0.5–3 m. Consult manufacturer and insert requirements.

Colour

Galvanized and polyester powder-coated (PPC)

Insert RAL colour requirement.

Galvanized only

Infill -
Type

Mitred

Square

Size

Consult manufacturer and insert requirements.

Rails -
Vertical

25 mm diameter round tube

25 x 25 mm square tube

30 mm diameter round tube

30 x 30 mm square tube

Horizontal

50 x 25 mm rectangular hollow section (RHS)

60 x 40 mm rectangular hollow section (RHS)

Fixing

Bolt down

In ground

On wall

Gates -
Pedestrian

Required

Single leaf, 1.2 m wide, or width to suit, consult manufacturer and insert requirements.

Not required

Vehicular

Required

Single or double leaf, 3.0 m wide, or width to suit, consult manufacturer and insert requirements.

Not required

Accessories/ Other requirements

Not required

Access control options

Fence toppings

Consult manufacturer and insert requirements.

Standard product features

Width:

2.932 m.

Posts:

Each post is manufactured using various rectangular hollow section (RHS) post sizes dependent on height:

  • 0.5–2 m height: 80 x 40 mm RHS.
  • 2–3 m height: 90 x 50 mm RHS.
  • Centres: 2980 mm.

Post to panel fixing:

Panel is fixed to the post using concealed lugs, bolted within the horizontal rails, which are in turn bolted to the posts via hidden fixings.

Infill centres:

129 mm.

Product Options

Product reference:

– Apex Railing, adjustable raking version:

Manufactured in the same manner as the standard version to prevent vertical movement of the infills, but designed to allow further adjustment so that the panels follow the ground contours of up to 1:4. Consult manufacturer for information.

Gates:

Framed in rectangular hollow section and tubular style railing infills to match the Apex Railing panel, and supplied with side latch, rubber bump stop and two suitable gate posts. Vehicular gates also include drop bolts.
