Altro Orchestra™
Verified by manufacturer 3 days ago
EPD
Certificate type
Acoustic PVC flooring.
Application
Suitable use in:
- School, kindergarten and university communal spaces and classrooms;
- Student accommodation and communal areas;
- Hospital and care home communal areas and patient/ resident rooms;
- Office circulation and communal areas;
- Retail;
- Hotel and leisure public and dining areas;
- Home adaptations/ social housing communal areas;
- Anywhere where the passage of sound must be reduced between storeys and within rooms.
Description
2.85 mm-thick, acoustic, heterogeneous PVC sheet with fleece back and Easyclean PUR surface protection. The sheet is available in a range of 40 colours, and is suitable for use with underfloor heating. A ten-year guarantee is included.
The flooring should be fixed using AltroFix™ adhesive, and joints must be grooved and hot welded using the matching colour Altro Weldrod™. Can be combined with the range of Altro wall cladding. Accessories are available for use with the flooring; contact manufacturer for information.
Features and benefits:
- Manufactured in accordance with BS EN 651.
- Electrical behaviour (to BS EN 1815): <2 kV antistatic.
- For use where comfort and sound reduction are important, cutting impact sound by up to 15 dB.
General information
Color | Beige Black Blue Brown Cream |
Finish | Smooth |
Material | Polyvinyl chloride (PVC) |
Shape | Rectangle |
Length | 20000 mm |
Width | 2000 mm |
Height | 2.85 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | M50/150 Sheeting M50/20 Sheeting |
Specification data - Foam-backed polyvinyl chloride (PVC) sheets
Use class | To BS EN ISO 10874, class 34/ 42. |
Width | 2000 mm. |
Thickness | 2.85 mm. |
Colour and pattern | Montezuma CH2845U.Falstaff CH2846U.Turandot CH2847U.Othello CH2848U.Orfeo CH2849U.Serpent CH2850U.Volta CH2851U.Chromatic CH2852U.Notturna CH2853U.Percussion CH2844U.Brass CH2842U.Porter CH2854U.Maraca CH2855U.Woodwind CH2843U.String CH2841U.Musette CH2856U.Aurora CH2857U.Figaro CH2858U.Polka CH2859U.Seville CH2860U.Timpani CH2861U.Tosca CH2862U.Marimba CH2863U.Cornet CH2864U.Carlotta CH2865U.Macavity CH2867U.Fidelio CH2868U.Sitar CH2869U.Elektra CH2870U.Kora CH2871U.Nabucco CH2873U.Reed CH2874U.Cello CH2829U.Trumpet CH2825U.Glockenspiel CH2827U.Guitar CH2828U.Rigoletto CH2876U.Traviata CH2877U.Bassoon CH2831U.Chant CH2814U.Club CH2815U.Metal CH2818U.Bongo CH2840U.Oboe CH2835U.Chimes CH2836U.Violin CH2834U.Drum CH2837U.Flute CH2833U.Trombone CH2839U.Manon CH2878U, Conga CH2879U.Reggae CH2801U.Salsa CH2802U.Flamenco CH2806U.Jazz CH2824U.Fusion CH2813U.Soul CH2817U.Rap CH2820U.Gospel CH2821U.Manufacturer guidanceConsult manufacturer and insert requirements. |
Product Reference | Altro Orchestra™ |
Slip resistance | To BS EN 13893: DS; to DIN 51130: R10. Guidance for specification option: to EN 13893. |
Sound insulation | To EN ISO 10140-3, ca. 15 dB. |
Weight | To EN ISO 23997, 2.6 kg/m2 |
Residual indentation | To EN ISO 24343-1, ≤ 0.20 mm. |
Flexibility | To EN ISO 24344, Pass. |
Lightfastness | To BS EN 20 105-B02, ≥6. |
Castor chair rating | To BS EN 425, Pass. |
Wear resistance | To EN 660-2, Group T. |
Chemical resistance | To EN ISO 26987, Good. |
VOC emissions | To CDPH 1350 / Floorscore Indoor Air Comfort Gold, Approved. |
Execution | The flooring should be fixed using AltroFix™ adhesive, and joints must be grooved and hot welded using the matching colour Altro Weldrod™. Can be combined with the range of Altro wall cladding. |
Fire rating (to BS EN 13501) | Class Cfl-s1 (≥4.5 kW/m² pass). |
Sustainability data
Material | Polyvinyl chloride (PVC) |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 7.56 kg CO₂ eq/m² |
Recyclability | 100% recyclable pre installation - ALTRO RECOFLOOR™ https://www.recofloor.org/ |
Third party certifications
Third party certifications
EPD
Altro Orchestra EPD
