Description

External wall insulation system classified with European Technical Approval Fire Protection Class A. Alprotect Nova combines unique patented carbon technology and nano-hybrid binders, resulting in a mineral wool external wall insulation system that sets new standards in terms of protection and durability. The system formulations can also be applied with light reflectance values as low as 5%, ensuring most shades of colour including dark ones and even black can be used successfully for the façades finish.

Features/ Benefits:

  • Maximum fire protection.
  • Patented carbon fibre technology.
  • UV stable.
  • Unrivalled impact strength from thin coat system.
  • Highest level of dark colours permissible.
  • 30% application time saving compared with conventionally reinforced systems.
  • Maximum level of crack resistance.
  • Enhanced protection from algae and fungal growth.

General information
Specification data
Product Reference

Alsecco Alprotect Nova

Sub primer

Sub Primer HT

Solvent-free synthetic-resin dispersion primer.

Sub Primer P

Synthetic-resin dispersion primer.

Insulation -
Adhesive

Armatop MP

Bonding compound.

Thermastick FW

Adhesive for bonding to most manufactured sheathing board substrates.

Type

Mineral Wool Dual Density

Mineral Wool High Density

Mineral Wool Lamella

Mineral Wool Slab

Mineral Wool Slab Plus

Thickness

Insert requirement, available 30–300 mm.

Mechanical fixings

Insert requirements, many options available dependent on individual application.

Reinforcement -
Type

Alsitex Nova

System mesh.

Panzer Heavy Duty Mesh

To prepare highly impact-resistant reinforcing layers, for use with Alsitex Nova mesh where high level of impact resistance required.

Basecoat

Armatop Nova

Ready to use paste applied to a thickness 4-5 mm.

Finish -
FinishType

Alsilite Sc Nova R

Nanohybrid-based, paste-like lightweight render with a grooved finish.

Alsilite Sc Nova T

Nanohybrid-based, paste-like lightweight render with a scraped finish.

Colour

Insert requirement, many options available, contact manufacturer for information.

Size

Insert requirement (mm).

Protective coating -
Paint

Not required

Alsicolor Carbon

Carbon-fibre reinforced silicone resin paint.

Alsicolor Finish

Acrylic-resin paint.

Alsicolor SC

Silicone-resin paint.

Colour

Insert requirement, many options available, contact manufacturer for information.

Accessories

None

Alsecco acrylic-based joint sealant

Alsecco aluminium profiles

Alsecco profile connectors and fixings

Alsecco PU foam

Alsecco PVC-U profiles

Alsecco sealing tape

Alsecco stainless steel profiles

Standard product features

Fire rating:

A2-s1, d0.

Product Options

Sub primer:

- Sub Primer HT:

  • Material: Acrylic-resin dispersion.
  • Colour: Opaque blue (transparent when dry).
  • Density: 1.0 g/cm³.
  • Drying time: 2–4 hours (approximate).

- Sub Primer P:

  • Material: Styrene acrylate dissolved in solvent.
  • Colour: Transparent.
  • Density: 0.82 g/cm³.

Insulation adhesive:

- Armatop MP:

  • Material: Cement-based, comprising limestone sand and additives.
  • Colour: Grey.
  • Density: 1.4 g/cm³.
  • Adhesive pull strength: ≥0.08 N/mm² (on polystyrene).
  • Capillary water absorption: w = <0.2 kg/(m²h^½).
  • Diffusion-equivalent air-layer thickness: sd = <0.1 m (at 2 mm).
  • Drying time: 1–3 days (approximate).

- Thermastick FW:

  • Material: Acrylate copolymer dispersion.
  • Colour: White.
  • Density: 1.65 g/cm³.
  • Drying time: 72 hours (approximate).

Reinforcement:

- Alsitex Nova Mesh:

  • Material: Multi-stranded alkali-resistant glass-fibres with a polymer coating.
  • Size: 4 x 4 mm.
  • Width: 1100 mm.
  • Weight: 160 g/m².
  • Colour: Red.
  • Tensile strength: Longitudinal: 2000 N/50mm; Transverse: 2000 N/50mm.

- Panzer Mesh:

  • Size: 6 x 6 mm.
  • Width: 1000 mm.
  • Weight: 330 g/m².
  • Colour: White.
  • Tensile strength: Longitudinal: 3200 N/50mm; Transverse: 3500 N/50mm.

Basecoat:

- Armatop Nova:

  • Material: Silicate-organo hybrid dispersion.
  • Colour: Cream.
  • Density: 1.4 g/cm³.
  • Capillary water absorption: w = 0.03 kg/(m²h^½).
  • Diffusion-equivalent air-layer thickness: sd = 0.26 m (at 4 mm).
  • Drying time: 1–3 days (approximate).

Thermal conductivity:

  • Mineral Wool Dual Density - 50–250 mm: 0.036 W/mK.
  • Mineral Wool High Density - 30 and 40 mm: 0.038 W/mK.
  • Mineral Wool High Density - 50–200 mm: 0.039 W/mK.
  • Mineral Wool Lamella - 30–300 mm: 0.042 W/mK.
  • Mineral Wool Slab - 40–260 mm: 0.036 W/mK.
  • Mineral Wool Slab Plus 40–200 mm: 0.038 W/mK.

Literature
Third party certifications
  • 96/3238 : Product page 5
