Acoustic Wall Panels – Solid Timber and Aluminium TIMBER EFFECT - Acoustic Wall Panels

Name: Acoustic Wall Panels – Solid Timber and Aluminium TIMBER EFFECT - Acoustic Wall Panels
Brand: BCL Timber Projects Ltd
SKU: 8ejRTxKh33kYgXfXHpUSpx

Verified by manufacturer 1 day ago

Solid Wood Slats - EN 13501 Tested

BCL Timber Projects Ltd

Product certifications:

PEFC
Certificate type
Health & Safety Accreditation
Certificate type
TRADA
Certificate type
Health & Safety Accreditation
Certificate type
Grown in Britain - GiB
Certificate type

BCL range of solid wood or aluminium 'TIMBER EFFECT' acoustic wall panels available with a vast range of customizable options.

Jump to:

+44 (0)118 934 4155 Website

Application

For internal wall lining applications.

Description

BCL range of solid wood or aluminium 'TIMBER EFFECT' acoustic wall panels.

Features and benefits:

Choice of solid wood or aluminium 'TIMBER EFFECT' acoustic wall panels.
Solid wood system has a wide range of timber options.
Up to 75% recycled content aluminium available.
'TIMBER EFFECT' achieves A1/ A2 fire rating; solid wood full system fire tested to EN 13501-1.
Wide choice of design shapes and slat dimensions.
Coloured acoustic fabric options.
Solid wood option FSC® and PEFC® certified with full BREEAM Mat03 credits.

General information

Color	Beige Black Blue Bronze Brown Copper Cream Green Grey Ivory Silver White Other Guidance for specification option: Choose from 25 timber species and 25 fabric colours. Show more
Finish	Woodgrain Veneered Wood grain Anti-graffiti Anti-microbial Antiqued Brushed Burnt Coated Flamed Gloss Grooved Lacquered Laminated Matt Micro-textured Natural Painted Powder-coated Pre-treated Sanded Satin Sawn Semi-gloss Grained Weathered Unfinished Other Show more
Material	Wood Timber Polyester fibre (PET) Aluminium Polyurethane Polyurethane (PUR) Show more
Shape	Rectangle Square Elliptical Oval Rhombus Trapezoid Triangle Other Show more
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	30 year

Uniclass	Ss_25_25_75_05 Acoustic panel lining systemsPrimary
CAWS	K13/160 Proprietary K13/160 Proprietary K13/170 Acoustic panel lining K13/170 Acoustic panel lining

Specification data - Acoustic panel lining systems

Classification data
System performance	- Manufacturer guidance Up to Class A acoustic performance (BS EN ISO 11654:1997) Up to Euroclass B-s2,d0 Reaction to Fire (EN13501-1) pre-tested options available. Please contact BCL for further information.
Battens	Direct fix. Guidance for specification option: Panels are fixed to wall using painted screws (matching fabric colour), located in between timber slats @ 600 mm ccs. Cannot be used for 'closed board' systems. BCL Wall Rail. Guidance for specification option: Panels are hung on to wall using a male-female carrier rail. Additional cost typically £10 / sqm. Cover batten. Guidance for specification option: Panels are fixed to wall and a timber 'cover slat' is bradnailed over panel junction to hide screws @ 600 mm ccs. Can only be used for systems w/ 19 mm thick timber slats.
Acoustic insulation	Acoustic fabric + 25 mm insulation at 45 kg/m³. Acoustic fabric + 50 mm insulation at 45 kg/m³. 12 mm MDF backing board (reflective). Guidance for specification option: Any RAL colour (reflective). Open-screen. Manufacturer guidance The acoustic fabric runs behind the timber slats and comes in several available ranges, varying in colours, texture and thickness. Multiple colours can also be combined across a system to generate distinctive looks or align with your client’s brand colours.
Panelling	-
Type	19 mm wide x 19 mm deep slats + 11 mm gap. Guidance for specification option: Class A acoustic. 19 mm wide x 44 mm deep slats + 21 mm gap. Guidance for specification option: Class A acoustic. 19 mm wide x 69 mm deep slats + 56 mm gap. Guidance for specification option: Class A acoustic. 19 mm wide x 94 mm deep slats + 51 mm gap. Guidance for specification option: Class A acoustic. 25 mm wide x 94 mm deep slats + 70 mm gap. Guidance for specification option: Class A acoustic. 25 mm wide x 119 mm deep slats + 95 mm gap. Guidance for specification option: Class A acoustic. 44 mm wide x 19 mm deep slats + 11 mm gap. Guidance for specification option: Class D acoustic. 44 mm wide x 19 mm deep slats + 16 mm gap. Guidance for specification option: Class C acoustic. 44 mm wide x 19 mm deep slats + 21 mm gap. Guidance for specification option: Class B acoustic. 44 mm wide x 19 mm deep slats + 31 mm gap. Guidance for specification option: Class A acoustic. 44 mm wide x 44 mm deep slats + 16 mm gap. Guidance for specification option: Class C acoustic. 44 mm wide x 44 mm deep slats + 21 mm gap. Guidance for specification option: Class B acoustic. 44 mm wide x 44 mm deep slats + 31 mm gap. Guidance for specification option: Class A acoustic. 44 mm wide x 144 mm deep + 106 mm gap. Guidance for specification option: Class A acoustic. 44 mm wide x 144 mm deep + 156 mm gap. Guidance for specification option: Class A acoustic. 69 mm wide x 19 mm deep slats + 21 mm gap. Guidance for specification option: Class C acoustic. 69 mm wide x 19 mm deep slats + 36 mm gap. Guidance for specification option: Class B acoustic. 94 mm wide x 19 mm deep slats + 8 mm gap. Guidance for specification option: Class D acoustic. 144 mm wide x 19 mm deep slats + 11 mm gap. Guidance for specification option: Class D acoustic. Random width 25, 44 and 94 mm wide slats + 15 mm gap. Guidance for specification option: Class C acoustic. Random width 25, 44 and 94 mm wide slats + 22 mm gap. Guidance for specification option: Class B acoustic. Random width 25, 44 and 94 mm wide slats + 31 mm gap. Guidance for specification option: Class A acoustic.
Surface material	Solid timber.
Surface finish	Smooth.
Fasteners	Secret fixings.
System accessories	- Manufacturer guidance Consult manufacturer and insert requirements or omit.
Third-party certification	Not required. FSC® certified. PEFC® certified. Manufacturer guidance Please contact BCL to determine which timber is certified FSC® or PEFC according to your requirements.
Profile	Square edge. Rounded. Triangular. Multiple. Guidance for specification option: Multiple shapes can be combined to create varying textures in wood. Insert requirements.
Timber species	Ash (US). Ash (EU). Ash (UK). Western red cedar. Larch (EU). Bamboo (light). Bamboo (medium). Bamboo (dark). Bamboo (strand woven). Sweet chestnut. European redwood. Cherry (US). American white oak. Douglas fir. Yellow poplar. Southern yellow pine. Red grandis. Obeche/ ayous. Oak (veneer) FR MDF. American black walnut (veneer) FR MDF. DragonWood (charred effect). Kebony (dark thermo-modified pine). Thermo euro-pine. Thermo ash (UK). Thermo poplar (UK). Accoya. Oak (solid). Alaskan yellow cedar.
Fabric colour	Plain - ash. Plain - grey. Plain - lemon. Plain - lilac. Plain - orange. Plain - peach. Plain - royal. Plain - sky. Plain - turquiose. Plain - volt. Plain - white. Felt - baltic 31. Felt - beger 12. Felt - blue 89. Felt - calm 87. Felt - crimson 11. Felt - desert 66. Felt - gardner 21. Felt - grey 38. Felt - grey 64. Felt - ivory 41. Felt - lagoon 964. Felt - lather 54. Felt - marmalade 142. Felt - maroon 5. Felt - metal 32. Felt - nature 58. Felt - ocean 11. Felt - ocre 68. Felt - oude 63. Felt - pink 124. Felt - scarlett 19. Felt - violet 731. Woodgrain - black 317. Woodgrain - cream 173. Woodgrain - dream 527. Woodgrain - fairy 52. Woodgrain - grain 402. Woodgrain - grey 634. Woodgrain - grey 713. Woodgrain - rose 843.
Colour	Manufacturer's standard.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Wood Timber Polyester fibre (PET) Aluminium Polyurethane Polyurethane (PUR)
Recyclability	BCL panels are easily demountable to be re-purposed or recycled at end of service life. Panels are simply unscrewed/ demounted and each component (timber, polyester fabric, PPC aluminium) can be easily separated and recycled individually. Typically 90–95% of any system can be easily recycled.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	30 % Guidance for specification option: Typically. Varies depending on panel configuration. BCL can provide exact recycled / organic / carbon content on request, specific to each project / order. Manufacturer guidance Recycled content typically varies between 20% - 30% , depending on volume of timber used. The recycled component comes from the Aluminium used within a panel system generally. Carbon offsetting / reduction comes from using more timber (which is virgin organic and not recycled, lowering recycled content) BCL can provide full recycled / organic & carbon analysis on every system order -- please contact BCL for more information on your system configuration.
