200 x 200 mm
One hour fire rated access panel with a beaded frame manufactured in 0.9 mm Zintec steel, and a plasterboard faced door.
For use as an access hatch, for application into plasterboard walls and ceilings from 8–32 mm thickness, including double boards. Will fit into the structural membrane of a joint-less plasterboard wall and ceiling system.
Designed for inspection purposes in areas where regular maintenance to services is required, rather than personnel access - consult manufacturer for details.
This panel is not acoustic or air pressure tested.
FlipFix Easy Install plasterboard door beaded frame access panels (exceed fd30 and fd60 fire door specification) are the easiest access panels to install on the market due to the unique FlipFix fitting device.
Fitting requires no battening out of the structural opening due to the unique FlipFix device which clamps the frame on to the rear of the plasterboard. It is manufactured with a beaded frame for tape and jointing/skim-coat plastering. The panels door leaf is locked in place via a budget lock as standard other lock options are available upon request.
Meets a minimum requirement of FR-30 and FR-60 specification.
Features and benefits:
Please Note: the structural opening is at least 5 mm larger than the panel size, back of frame size. E.G a 600 x 600 mm panel size requires a 605 x 605 mm hole size.
Color | White |
Finish | Gloss |
Material | Steel Plasterboard |
Shape | Square Rectangle |
SizeBespoke sizes available. Consult manufacturer for details. | - |
Length | 200 mm 150 mm 300 mm 450 mm 550 mm |
Width | 150 mm 200 mm 300 mm 450 mm 550 mm |
Height | 60 mm |
WarrantyDescription | Ten year |
Uniclass | |
CAWS | K10/430 Access panels K40/280 Access units |
Product range |
Fire resistance | 60 minutes to BS 476-22. |
Position | Ceiling mounted.Wall mounted. |
Panel | - |
Material | Plasterboard.Door. |
Integral finish | RAL 9010, 30% glossOther colours are available on request, consult manufacturer for details. |
Latch or lock type | Budget lock.Other lock options are available on request, consult manufacturer for details. |
Standard | To BS EN 1363-1. |
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
