Summary
Stainless Steel lift out sealed floor access doors. Virtually invisible when installed. EPDM seal. Loadings up to 125 kN, insulated, shallow and Fire Rated up to 90 Minutes.
-
-
Application
Easy-to-open design accommodates a variety of flooring tiles and ceramic finishes.
-
-
Description
SBVE Range is manufactured from stainless steel grade 304 with an EPDM Seal. Available with infill depth of 27mm (Shallow) or 52mm.
Features and benefits:
- Up to 125 kN test load (EN 124).
- Available as lift out, fire rated (90 minutes), insulated hinged and shallow.
- Sealed access cover in high-quality finish.
- Complete with EPDM seal.
- The cover is reinforced with a clamped steel mesh reinforcement.
-
-
Shape
Rectangle, Square
-
-
Material
Steel, Rubber
-
-
Size
200 x 200 mm, 300 x 300 mm, 400 x 400 mm, 450 x 450 mm, 500 x 500 mm, 600 x 400 mm, 600 x 600 mm, 635 x 635 mm, 700 x 700 mm, 800 x 600 mm, 800 x 800 mm, 1000 x 600 mm, 1000 x 800 mm, 1000 x 1000 mm
-
-
Specification
Classification data
Configuration
Lift out.
-
-
Finish
Self-finish.
-
-
Load class (minimum)
Not required., 125 kN.
-
-
Frame or support
Stainless Steel Grade 304., Stainless Steel Grade 316.
-
-
Additional properties
Size:
450 x 450 mm., 635 x 635 mm., 700 x 700 mm.
-
-
FireRating
90 minutes.
-
-
Infill depth
52 mm.
-
-
Cover depth
75 mm.
-
-
CoverMaterial
Stainless Steel Grade 304., Stainless Steel Grade 316.
-
-
Hardware
Stainless steel screws.
-
-
Locking
-
-
-
Seal
EPDM rubber.
-
-
Reinforcement
Steel mesh.
-
-
