SVK Fibre Cement Cladding
SVK Fibre Cement Cladding
SVK Fibre Cement Cladding

Last verified by manufacturer over a year ago

Taylor Maxwell

Last verified by manufacturer over a year ago

Taylor Maxwell

Last verified by manufacturer over a year ago

Taylor Maxwell
Summary
Flat fibre – reinforced cement panels, used in back ventilated and drained rain-screen cladding systems.
-
-
Application

External façade installations. Suitable for use on a new building, refurbishment or re-cladding project.

-
-
Description

Comprised of cement, PVA, cellulose fibres, aggregates and water, these cement cladding boards are available in standard sizes including 3050 x 1220 x 8 mm and 2520 x 1220 x 8 mm. There is also the option to create made-to-measure alternatives for individual projects. These flat fibre – reinforced cement panels, used in back ventilated and drained rain-screen cladding systems, provide a decorative and protective façade over timber-frame, steel frame or masonry external walls of new and existing buildings.


This strong and versatile range of cladding boards is suitable for use as an external façade panel and the naturally finished PuroPlus board has been tested to CWCT standards. During the production process, all product waste including the dust from sawing and polishing are incorporated into the next production process. Once a fibre cement panel reaches the end of its design life, it can be crushed and then used again in a new fibre cement production process. Cement fibre cladding panels combine seamlessly with several other façade materials, including facing bricks and stone and can be installed using a variety of fixing methods.


Features and benefits:

  • A2, s1-d0 fire rating in accordance with EN13501-01: 2018 (Section 7 BBA certificate number 22/5993).
  • European Technical Approval (ETA) covering Ornimat, Decoboard, Puro Plus and Colormat ranges.
  • Resistant to mould, rot and bacteria.
  • Easy to clean using clean water, with a mild detergent if required.
  • Supported by a 10-year manufacturer material and colour guarantee* Decoboard and Ornimat ranges.
  • Independently tested to CWCT standards – The Centre for Window and Cladding Technology.
  • Durability – under normal UK service conditions, the panels will have a service life of at least 30 years (see section 10 of BBA Certificate number 22/5993).
-
-
Product certifications
-
-
Color
Other
-
-
Finish
Other
-
-
Material
Cement, Timber, Steel
-
-
Shape
Other
-
-
Length
2520 mm, 3050 mm, Bespoke
-
-
Width
1220 mm, Bespoke
-
-
Height
8 mm, Bespoke
-
-
Warranty description
Ten year
-
-

Specification

Thermal insulation
-
-
-
Breather membrane
-
-
-
Material
-
-
-
Fasteners
-
-
-
Secondary support structure
Aluminium carrier rails., Stainless steel carrier rails., Timber carrier rails.
-
-
Cavity fire barriers
-
-
-
Horizontal
-
-
-
Vertical
-
-
-
Cladding panels
-
-
-
Material
Fibre-reinforced cement boards.
-
-
Panel joints
Open joints.
-
-
Reveals
-
-
-
System accessories
-
-
-

Additional properties

Panel Type
Colourmat Classic.
-
-
Fixing
Screws., Rivets., Invisible mechanical fastening.
-
-
Surface finish
Water repellent transparent protective layer.
-
-
Colour
-
-
-
Panel size
3050 x 1220 x 8 mm., 2520 x 1220 x 8 mm., Made to measure.
-
-
Density
1600 ± 50 kg·m‾³.
-
-
