Summary
Acoustic panels for direct fixing to walls, ceilings and soffits.
Acoustic panels for direct fixing to walls, ceilings and soffits.
Acoustic panels for direct fixing to walls, ceilings and soffits.
Application
Suitable for cellular offices, corridors, receptions, entrance halls, waiting rooms, team work spaces and other public areas where visual appeal and sound quality are equally important.
Suitable for cellular offices, corridors, receptions, entrance halls, waiting rooms, team work spaces and other public areas where visual appeal and sound quality are equally important.
Suitable for cellular offices, corridors, receptions, entrance halls, waiting rooms, team work spaces and other public areas where visual appeal and sound quality are equally important.
Description
Ecophon Focus Levels acoustic ceiling and wall panel system is a creative system with different thicknesses, sizes and colours. The system is glued edge-to-edge directly to an existing soffit, ceiling or wall.
Features and benefits:
- Absorption class B.
- Painted edges.
- Different panel thickness and sizes creates distinctive patterns.
Ecophon Focus Levels acoustic ceiling and wall panel system is a creative system with different thicknesses, sizes and colours. The system is glued edge-to-edge directly to an existing soffit, ceiling or wall.
Features and benefits:
- Absorption class B.
- Painted edges.
- Different panel thickness and sizes creates distinctive patterns.
Ecophon Focus Levels acoustic ceiling and wall panel system is a creative system with different thicknesses, sizes and colours. The system is glued edge-to-edge directly to an existing soffit, ceiling or wall.
Features and benefits:
- Absorption class B.
- Painted edges.
- Different panel thickness and sizes creates distinctive patterns.
Product certifications
Color
Beige, Black, Blue, Brown, Green, Grey, Orange, Pink, White, Yellow, Clear, Bronze, Copper, Cream, Gold, Ivory, Purple, Red, Silver, Turquoise, Other
Beige, Black, Blue, Brown, Green, Grey, Orange, Pink, White, Yellow, Clear, Bronze, Copper, Cream, Gold, Ivory, Purple, Red, Silver, Turquoise, Other
Beige, Black, Blue, Brown, Green, Grey, Orange, Pink, White, Yellow, Clear, Bronze, Copper, Cream, Gold, Ivory, Purple, Red, Silver, Turquoise, Other
Finish
Coated
Coated
Coated
Material
Glass mineral wool
Glass mineral wool
Glass mineral wool
Shape
Square, Rectangle
Square, Rectangle
Square, Rectangle
Length
600 mm, 1200 mm
600 mm, 1200 mm
600 mm, 1200 mm
Width
300 mm, 600 mm
300 mm, 600 mm
300 mm, 600 mm
Height
20 mm, 30 mm, 40 mm
20 mm, 30 mm, 40 mm
20 mm, 30 mm, 40 mm
Warranty description
Ten year
Ten year
Ten year
SKU Code
Ecophon Focus Levels acoustic ceilings and wall panels
Ecophon Focus Levels acoustic ceilings and wall panels
Ecophon Focus Levels acoustic ceilings and wall panels
Specification
Standard
To EN 13964:2014.
To EN 13964:2014.
To EN 13964:2014.
Third-party certification
Eurofins Indoor Air Comfort® IAC, French VOC A, Finnish M1.
Eurofins Indoor Air Comfort® IAC, French VOC A, Finnish M1.
Eurofins Indoor Air Comfort® IAC, French VOC A, Finnish M1.
Form
Panel.
Panel.
Panel.
Rigidity
Rigid.
Rigid.
Rigid.
Application
Ceiling mounting., Soffit mounting., Wall mounting.
Ceiling mounting., Soffit mounting., Wall mounting.
Ceiling mounting., Soffit mounting., Wall mounting.
Material
Glass wool.
Glass wool.
Glass wool.
Acoustic performance
-
-
-
Purpose
Absorber.
Absorber.
Absorber.
Sound absorption
Class C to BS EN ISO 11654.
Class B to BS EN ISO 11654.
Class A to BS EN ISO 11654.
Fire performance
-
-
-
Reaction to fire
To EN 13501-1, Class A2-s1, d0.
To EN 13501-1, Class A2-s1, d0.
To EN 13501-1, Class A2-s1, d0.
VOC emissions
E1.
E1.
E1.
Dimensions
-
-
-
Size (length x width)
600 x 600 mm., 1200 x 300 mm., 1200 x 600 mm.
600 x 600 mm., 1200 x 300 mm., 1200 x 600 mm.
600 x 600 mm., 1200 x 300 mm., 1200 x 600 mm.
Thickness (overall)
20 mm.
30 mm.
40 mm.
Edges
Square.
Square.
Square.
Finish
Akutex™ FT.
Akutex™ FT.
Akutex™ FT.
Colour
White frost., Moonlight sky., Highland fog., Sunset heat., Ocean storm., Morning drizzle., Peach rose., Goji berry., Scallop shells., Fresh clover., Sage garden., Eucalyptus leaf., Summer forest., Golden field., Ruby rock., Wet sand., Silent steam., Dark diamond., Cloudy day., Volcanic ash., Silver stone., Silk slate.
White frost., Moonlight sky., Highland fog., Sunset heat., Ocean storm., Morning drizzle., Peach rose., Goji berry., Scallop shells., Fresh clover., Sage garden., Eucalyptus leaf., Summer forest., Golden field., Ruby rock., Wet sand., Silent steam., Dark diamond., Cloudy day., Volcanic ash., Silver stone., Silk slate.
White frost., Moonlight sky., Highland fog., Sunset heat., Ocean storm., Morning drizzle., Peach rose., Goji berry., Scallop shells., Fresh clover., Sage garden., Eucalyptus leaf., Summer forest., Golden field., Ruby rock., Wet sand., Silent steam., Dark diamond., Cloudy day., Volcanic ash., Silver stone., Silk slate.
Accessories
Not required., Connect Absorber glue.
Not required., Connect Absorber glue.
Not required., Connect Absorber glue.
Additional properties
Moisture resistance
To EN 13964:2014, Class C (relative humidity 95% and 30°C).
To EN 13964:2014, Class C (relative humidity 95% and 30°C).
To EN 13964:2014, Class C (relative humidity 95% and 30°C).
Sustainability data
Contains Red List materials
No
No
No
Country of material origin
Sweden
Sweden
Sweden
Country of product manufacture
Sweden
Sweden
Sweden
Material
Glass mineral wool
Glass mineral wool
Glass mineral wool
A1–A3 ('Production stage')
Embodied carbon as defined in BS EN 15804
Lower emissions
Lower emissions
Lower emissions
Normalized unit
-
-
-
Declared unit
4.32 kg CO₂ eq/m²
Certified
4.32 kg CO₂ eq/m²
Certified
4.32 kg CO₂ eq/m²
Certified
Recyclability
100%
100%
100%
Recycled content
64 %
64 %
64 %
Expected Life
50 year
50 year
50 year
