Summary
Expanded polystyrene (EPS) panels designed for passive venting of ground gases from beneath a building to the atmosphere via perimeter vents. Available in a range of depths and compressive strengths.
-
-
Application
For use under suitably reinforced concrete ground floor slabs.
-
-
Description
It provides a passive gas venting medium. When used in combination with perimeter vents and a suitable gas membrane system, it will provide an effective method of protecting structures against the ingress of harmful ground gases.
Features and benefits:
- Highly effective venting medium suitable for ground gas affected sites as part of a gas protection system.
- Provides a high degree of insulation and is manufactured from expanded polystyrene which achieves a BREEAM rating of A+.
- Range of thicknesses and grades to suit most project requirements.
- Light, robust and easy to install panels.
- Ventform panels are resistant to UV light, water and are flame retardant. They contain no CFCs or HCFCs.
-
-
Digital objects
-
-
Color
White
-
-
Material
Polystyrene
-
-
Shape
Square
-
-
Length
1200 mm
-
-
Width
1200 mm
-
-
Height
80 mm, 100 mm, 150 mm, 200 mm
-
-
Specification
Classification data
Third-party product certification
BBA Agrement certificate.
-
-
Thickness overall
100 mm.
-
-
Loadbearing capacity
50 kN/m².
-
-
Additional properties
BREEAM rating
A+.
-
-
UV resistance
Yes.
-
-
Water resistance
Yes.
-
-
Flame retardant
Yes.
-
-
Dimensions
1200 x 1200 mm.
-
-
Leg length
60 mm.
-
-
Colour
White.
-
-
Ventilation
13 200 mm² per m width of floor.
-
-
ThermalConductivity
0.033 W.mK.
-
-
Sustainability data
Country of product manufacture
United Kingdom
-
-
Material
Polystyrene
-
-
Recyclability
-
-
-
