Summary
Fire protection to general building services.
Fire protection to general building services.
Application
Provide fire protection to service enclosures.
Provide fire protection to service enclosures.
Description
For the provision fire resisting constructions to general building service enclosures, 120 or 240 minutes fire resistance (integrity only) in accordance with performance criteria of BS 476-20.
Promat constructions have been tested in accordance with the criteria of BS 476-20 and assessed to the criteria of BS 476-24. These assessments include allowance for both internal and external fire.
Features and benefits:
- Boards can be installed before the building is watertight and are suitable for areas where the humidity is up to 85%.
- 30–240 minutes fire resistance.
- 30 plus years proven, performance.
- High temperature environments (up to 80°C).
- Slim constructions.
- Multiple applications.
- Early installation for faster build.
- To BS 476-20 and BS 476–24: 1987.
For the provision fire resisting constructions to general building service enclosures, 120 or 240 minutes fire resistance (integrity only) in accordance with performance criteria of BS 476-20.
Promat constructions have been tested in accordance with the criteria of BS 476-20 and assessed to the criteria of BS 476-24. These assessments include allowance for both internal and external fire.
Features and benefits:
- Boards can be installed before the building is watertight and are suitable for areas where the humidity is up to 85%.
- 30–240 minutes fire resistance.
- 30 plus years proven, performance.
- High temperature environments (up to 80°C).
- Slim constructions.
- Multiple applications.
- Early installation for faster build.
- To BS 476-20 and BS 476–24: 1987.
Shape
Rectangle
Rectangle
Color
White
White
Finish
Smooth, Untreated
Smooth, Untreated
Material
Calcium silicate
Calcium silicate
WarrantyDescription
-
-
Size
2440 x 1220 mm, 2500 x 1250 mm
2440 x 1220 mm, 2500 x 1250 mm
Specification
Classification data
Fire rating
To BS EN:13501-1, Class A1.
To BS EN:13501-1, Class A1.
Thickness
9 mm., 12 mm.
20 mm., 25 mm.
Edges
Square.
Square.
Colour
Off-white.
Off-white.
Additional properties
Certification
Assessment WF No 168498.
Assessment WF No 168498.
Span (maximum)
600 mm.
600 mm.
Fillet strips
-
-
Face layer
-
-
Fasteners
M4 self tapping screws., M4 screws into non combustible plugs.
M4 self tapping screws., M4 screws into non combustible plugs.
System accessories
PROMASEAL® Intumescent Sealant.
PROMASEAL® Intumescent Sealant.
System position
Promat SUPALUX® service enclosure can be installed horizontal or vertical.
Promat SUPALUX® service enclosure can be installed horizontal or vertical.
Fire protection
120 to 240 minutes integrity.
120 to 240 minutes integrity.
Substrate
Solid or structural wall/floor that provides at least the same fire performance as required from the Promat SUPALUX® system.
Solid or structural wall/floor that provides at least the same fire performance as required from the Promat SUPALUX® system.
Moisture
Up to 80%.
Up to 80%.
Surface finish
Untreated., Smooth.
Untreated., Smooth.
Dimensions
2440 x 1220 mm.
2500 x 1250 mm.
