Dreen®Ceramica - Ceramic slab system
Dreen®Ceramica - Ceramic slab system
Dreen®Ceramica - Ceramic slab system

Verified 1 month ago

Zoontjens

Verified 1 month ago

Zoontjens

Verified 1 month ago

Zoontjens
Summary
Complete lightweight ceramic-based paving slab and pedestal system for rooftop terraces.
-
-
Application

Suitable for the creation or renovation of rooftop terraces, balconies, podiums and walkways.

-
-
Description

Dreen®Ceramica is the luxury ceramic-based slab system for rooftop terraces, podiums and balconies. Ceramic slabs are used to extend the interior space into the outdoor space. It is colourfast, wear-resistant, frost-proof and low-maintenance.


Dreen®Ceramica ceramic slabs give any rooftop terrace a modern and streamlined look and feel. Their excellent anti-slip qualities make them suitable for use on the roof. These dimensionally stable slabs are available in a range of sizes. Because of their light weight, the slabs are also very suitable for renovating rooftop terraces or walkways, with the patented and tested pedestal design preventing any issues with possible wind uplift.


The slabs are attached to the underlying Fixplate lock system with removable corner sections. These elements fix and lock the slabs in place, but keeps the underlying roofing layer accessible if and when needed. It also ensures straight joints. DNS® enables us to raise the ceramic slabs to a greater height. Ceramic slabs of 90 x 90 cm can only be raised by using DNS®Large.


Features and benefits:

  • Colourfast - monolithic full-core coloured.
  • Scratch resistant.
  • Wear and frost resistant.
  • High dimensional stability.
  • High anti-slip (R11).
  • Maintenance free.
  • Dirt repellent.
  • Manufactured from compressed layers of clay baked at a high temperature.
  • Concrete, stone and wood look colour options.
  • Creates a stable and level walking surface.
  • Raised to the required height with adjustable pedestal system to guarantee a level terrace.
  • Satisfies all European standards.
-
-
Color
Black, Brown, Cream, Grey, White, Other
-
-
Material
Ceramic
-
-
Shape
Square, Rectangle
-
-
Length
600 mm, 900 mm
-
-
Width
450 mm
-
-
Height
20 mm, Bespoke
-
-

Specification

Classification data
Pedestals
Fixplate lock system., Fixplate Lock with adjustable supports., Class A1 Metal Fixplate lock with adjustable support., Fixplate lock system with adjustable supports suitable for BroofT4 solutions.
-
-
Paving units
Ceramic-based slab.
-
-
Applied surface features
Slip-resistant.
-
-

Additional properties

Dimensions
600 x 600 x 20 mm.
-
-
Size (mm)
598 x 598 x 20 mm.
-
-
Weight
16.5 kg (per slab); 46 kg/m².
-
-
Thickness tolerance
0.5 mm (approximate).
-
-
Tolerances
0.8 mm (approximate).
-
-
Slip resistance
R11., R13.
-
-
Load at fracture
11 kN.
-
-
Colour
Boost White, Boost Grey, Boost Smoke, Boost Tarmac, Trust Titanium, Brave Grey
-
-

Sustainability data

Country of material origin
Italy
-
-
Country of product manufacture
Italy
-
-
Recyclability
The slabs can be picked-up, removed and reused.
-
-
