Binns Canada Truckstopper 5

Truckstopper 5 is one of the shallowest impact tested bollards availableon the market today, with a foundation depth of just 400mm, reducing the need to re-divert utilities. This allows for installation at a fraction of the cost of traditional bollards.

Unlike traditional steel tube bollards, Binns truckstopper 5 utilises our patented spring steel design, creating a durable, ultra slimline product that is ideal for blending into the public realm.

Truckstopper 5 is single tested, so does not need to be installed in an array. The system is designed to follow the contours of the ground so can manoeuver around corners, bends, and can be installed on an incline.

Truckstopper 5 Specification Details

Shroud Diameter -273mm Diameter

Bollard Spacing-1400mm Centres, 1200mm Spacing Between Tested Cores

Height Above Ground -1050mm

Security Rating -BSI PAS 68:2010 V/7500(N3)/80/90:6.0/18.8

Tested Core Dimensions -200mm W X 200mm L X 1050mm H From Ffl

Minimum Array -Three

Cover Material -316 Satin Polished Stainless Steel As Standard

Ral Options -ANY STANDARD RAL COLOUR

Foundation Depth -400mm

Finishes

Oval 316 stainless steel mitre top cover with up to 2 hi-vis bands as standard. Alternative finishes available. Please contact your sales representative for more details.

Banding colour options

• Black
• Yellow
• Red
• Blue
• Orange
• White
• No banding
