Automatic aluminium sliding or swing door operator suitable for all commercial environments. Manufactured in the UK from aluminium with double or single glazing. Adjustable door speed, time and width via control unit.

Features and benefits:

Available in sliding or swing configurations.
Sliding doors can be manufactured as standalone doors or with side screens, pocket doors or made fully automatic with side screen safety sensors.
Doors can be single sliding or bi-parting.
Swing doors can be manufactured as single or pairs of doors.

Sliding doors features and benefits:

Electronic safety reverse, highly sensitive reverse settings in both open and close directions.
Finger trap safety.
Door speed safety, automatically adjusted based on door weight and resistance.
Fire alarm functions, door closes while the photocell is switched off and radar sensor remains active, manual operation and sequence doors setting can be cancelled.
Electronic lock activated by the program switch.
Battery backup an option in case of power failure.
Power: 230 V, 50 Hz, 2 A, single phase, 80 W.
Control unit: computerized self monitoring.
External connectors: four programmable inputs and one programmable output.
Draught prevention: totally sealed with brushes and rubber gaskets.

Swing features and benefits:

Can be used as automatic door control system to provide fire and smoke protection.
Extendable with master-slave function (two overlapping door leaves).
Available in both full power and low energy models.
Operator also available as INVERSE, FIRE and in-ground models.
DIN 18 650-compliant technology, approved worldwide.
Approved as a hold-open system for fire protection barriers.
Available to operate doors in sizes EN4 to EN6.
Smooth in operation.
Easy to maintain.
Drive housing available in stainless steel or aluminium. The easiest to use, LCD digital display control panel of any system. Automatic swing door units can also be used as smoke vent units.
Next Doors Ltd's automatic swing door operators are also fire rated at FD60.
