Westerham Bike Rack
Application

Cycle storage.

Description

The Westerham is designed to be used with the cyclist's own D-lock or cable lock. Depending on lock used, it secures the frame and both wheels to the rack.

Features and benefits:

Three locking points.

Application:

Cycle storage.

General information

Color

Black (Other colours available on request)

Features

3 locking points

Finish

Zinc oxide primed and polyester powder coated

Material

Mild steel

Size

1500 x 112 mm

Uniclass 2015

Pr_40_30_21_12 Carbon steel cycle standsPrimary

CAWS

Q50/210 Cycle stands

Q50/30 Street furniture

Specification data - Carbon steel cycle stands

Product Reference

Westerham Bike Rack

Stand type

Vertical

Number of stands

One

Base

Vertical channel fixed via three holes in the back face, using M8 75 mm long shield anchor bolts/ self-tapping bolts for concrete or brick walls

Finish as delivered

Galvanized

For indoor and outdoor use.

Galvanized and polyester powder coated

For indoor and outdoor use.

Zinc oxide primed and polyester powder coated – For indoor use only.

For indoor use only.

Colours

Not applicable

For Galvanized only.

Black

Standard for powder coated.

Special order

Insert requirement.

Accessories

None

Wall bolts

Standard product features

Colour:

Black or other colours available on request.

Features:

Three locking points.

Material:

Carbon steel.

Size:

1500 x 112 x 112 mm (h x d x w).

Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
- 1 2.1
Download now from NBS National BIM Library
