Werkman Platinum Range - Vacuum Insulated Glass

The Platinum Range is 10.3mm thick and part of the most versatile vacuum insulated glass ranges in the world, available in both an 8mm powder glass edge joint and an 8mm metal welded edge joint.

Manufactured at a thickness of 10.3 mm in toughened glass to suit timber and steel profiles and stone rebates, it is suitable for architects and specifiers working on listed properties or those in conservation areas and all domestic and commercial applications, as well as new windows in modern materials.

Werkman Tech's Platinum Range of vacuum insulated glass, or VIG, stands at the forefront of vacuum technology with virtually invisible nano pillars, toughened glass units, ultra thin edge joints and 1mm needle getters.

Comes with a manufacturers guarantee of 25 years and very strong environmental credentials in its design by avoiding the use of gasses, plastics or butyl rubber as found in slimline and double glazing.

Features and benefits:

• U-Value: 0.452W/(m2.K).
• Lowest U value 0.252W(m2.K.)
• Toughened glass.
• 8 mm edge seal in glass powder or metal welded.
• 1 mm Needle getter.
• Acoustic reduction 39 dB.
• Maximum size: 3600 x 2000 mm.
• Available in various hybrid options and specifications to suit all new works and all different UPVC and Aluminium frame depths and the ultimate U value option to replace double/triple glazing.
• Available in opaque/frosted options.
