Weathered Oak Decking

Name: Weathered Oak Decking
Brand: oDxNUNyTZHPNjNwUr7dQG8
SKU: dKxttKhpmMVukZue7zYuXr

Millboard Company Ltd, The

Composite decking boards with the timeless dignity of aged oak.

Jump to:

+44 (0)24 7643 9943 www.millboard.co.uk

Application

Use Millboard decking for all standard outdoor flooring applications (e.g. in residential, commercial, education, healthcare, leisure and hospitality) including the following:

Ground level terraces/ patios.

Roof level terraces.

Balconies (subject to Building Control).

Podium decks.

Public spaces/ areas.

Pathways.

Boardwalks.

Pool surrounds.

Jetties/ pontoons/ marinas.

Description

Millboard decking board is a polyurethane resin mineral board, hand-moulded from real oak, and hand-finished. Millboard decking is slip-resistant, splinter-free, anti-static and its non-porous composition makes it resistant to algae and insect infestations. UV and weather-stability, stain resistance and resistance to rotting and warping, make it a low maintenance product for use in all standard outdoor flooring applications. To be used with Millboard Durafix® stainless steel screw fixings.

Features and benefits:

100% wood-free and hand-moulded, on three sides, to give a real-wood grain representation.

Unique Lastane® finish provides low slip potential, and is resistant to scratches, food and drink stains, and everyday wear and tear.

Millboard Durafix® stainless steel screw fixings sink into the Lastane® material to achieve a virtually indistinguishable mark.

Non-porous composition makes it resistant to algae, insects and liquids (including fats, food, drink and urine).

No need to leave a ventilation gap when installing.

Manufactured under ISO 9001:2015 Quality Standards, ISO 14001 Environmental Standards and OHSAS 18001:2007 Occupational Health and Safety Standards.

Boards can be ground down and recycled, as building materials, at the end of their useful life.

Applications:

Use Millboard decking for all standard outdoor flooring applications (e.g. in residential, commercial, education, healthcare, leisure and hospitality) including the following:

Ground level terraces/ patios.

Roof level terraces.

Balconies (subject to Building Control).

Podium decks.

Public spaces/ areas.

Pathways.

Boardwalks.

Pool surrounds.

Jetties/ pontoons/ marinas.

General information

Material	The structural core of Millboard decking is a blend of natural minerals bonded in a polymer resin, with long fibre reinforcement for mechanical strength and durability The top surface is a textured, resilient Lastane® layer which is chemically melded to the core and hand-tinted using 2K component pigments that resist fading and UV damage
Size	200 x 32 x 3600 mm
Uniclass 2015	Pr_25_71_63_72 Recycled plastics deck boardsPrimary
CAWS	Q55/110 Deck Q55/380 Deck boards

Specification data - Recycled plastics deck boards

Product Reference	Weathered Oak Decking
Colour	Driftwood Embered Vintage
Fixings	Millboard Durafix® stainless steel T15 decking screws 4.5 x 60 mm Millboard Durafix® stainless steel T15 decking screws 4.5 x 45 mm Millboard Durafix® stainless steel T15 fascia screws 4.5 x 35 mm
Finishing profiles	Flexible Bullnose edging Square edging Bullnose Board Fascia
Sub frame	DuoSpan 51 mm Joist DuoSpan 99 mm Joist DuoSpan 136 mm Beam Plas-Pro 100 x 100 mm Post
Joist supports	DuoLift 15-60 mm Joist Cradle DuoLift 20 mm Self-Levelling Joint DuoLift 45 mm Riser DuoLift 45 mm Foot DuoLift Acoustic Separation Pad DuoSpan 136 mm Beam Plas-Pro 100 x 100 mm Post

Standard product features

Size:

200 x 32 x 3600 mm.

Material:

The structural core of Millboard decking is a blend of natural minerals bonded in a polymer resin, with long fibre reinforcement for mechanical strength and durability.

The top surface is a textured, resilient Lastane® layer which is chemically melded to the core and hand-tinted using 2K component pigments that resist fading and UV damage.

Surface finish:

Moulded from hand selected antique oak samples.

Edge detail:

Square.

Joist spacing:

The Weathered Oak boards need to be supported at 400 mm centres for residential applications, for commercial applications, bridges, balconies and steps this needs to be reduced to 300 mm centres.

Board spacing:

4 mm gap between boards, 1 mm gap at the ends of the boards.

Warranty:

25 year residential limited warranty.

Five year commercial limited warranty.

Technical Performance:

Slip Resistance (BS 7976-2:2002+A1:2003 using slider 96): 41-56 (Wet) 54-79 (Dry).

Reaction to fire (EN 13501-1:2007 + A1:2009): Bfl - s1.

Surface static resistance (IEC 62631-3-23): 6.5E+10 Ω/sq (6.4 x 10⁹).

Resistance to staining (BS EN 438-2: 2005): No visible change.

Resistance to static indentation (MOAT 27:1983): 0.1 mm.

Soft body impact (MOAT 43:1987): 0 mm.

Hard body impact (MOAT 43:1987): 0 mm.

Impact resistance after aging (BS EN 13245-1:2010): No cracking or damage to topcoat.

Taber abrasion (BS EN ISO 7784-2:2006): 261 mg.

Dimensional stability (65-85% relative humidity- BS EN 318: 2002): 0.47mm/m.

Dimensional stability (65-30% relative humidity - BS EN 318: 2002): -0.30mm/m.

Thermal conductivity: 0.089 W/mK when tested with FOX 200 heat flow meter.

Product Options

Installation:

For all applications Millboard decking boards to be installed with a 4mm gap between the boards and a 1 mm gap at butt ends, to facilitate drainage. There is no need for a ventilation gap to be left under Millboard decking boards. The maximum unsupported overhang for the boards is 50 mm, each cut board must be supported by a minimum of three joists. Each board must be screwed down with 2 x Millboard Durafix® stainless steel screw fixings where a board crosses a joist, and 3 x Millboard Durafix® stainless steel screw fixings at the ends of the boards.

Ground level application (soft surface):

Millboard decking boards installed over DuoSpan 99 mm Joists and Beams, Beams supported by Plas-Pro Posts concreted into the ground. Installed with DuoSpan brackets to the recommendations set out in installation guide found on manufacturers website.

Hard surfaces application (roof terrace, concrete base):

Millboard decking boards installed over DuoSpan Joists, Joists supported by DuoLift joists supports onto a solid/stable base. Installed with DuoSpan brackets to the recommendations set out in installation guide found on manufacturers website.
