Verified by manufacturer 1 month ago
KIWA BDA
Certificate type
Third-Party Accredited BDA Cementitious flexible waterproofing membrane for the protection of basement structures. Type A barrier Tanking solution in accordance with BS8102:2022 accepted by NHBC
Waterproofing of:
• Podium decks, flat roofs, terraces and balconies
• Water-retaining structures such as water tanks and
reservoirs
• Earth-retaining foundation walls to both the positive
and negative pressure
• Internal concrete surfaces of walls and rafts or slabs to
earth-retained structures such as basements,
METHOD OF APPLICATION
• Squeegee
• Roller
• Airless Spray
• Pin Leveller
• Brush
• Trowel
Cementitious coating for the waterproofing and protection of concrete and masonry. Can be spray-applied so ideal for large projects. Suited to the waterproofing of reservoirs, tunnels, water tanks, basements, podium decks, flat roofs and balconies.
Features and benefits:
Curing:
Color | Grey |
Finish | Cement Guidance for specification option: Smooth, matt grey coating. |
Material | Cementitious Guidance for specification option: Cementitious flexible waterproofing membrane. |
Shape | Other Guidance for specification option: 2 mm thick waterproof membrane. |
Warranty description | Lifetime Guidance for specification option: Newton 107F is guaranteed to resist weathering for up to 10-years. The membrane is not UV colour stable and will slightly fade in colour over time, and it may take a few months for the colour to be consistent. Over time discolouration due to weathering may take place, but the membrane will be serviceable |
Uniclass | |
CAWS | J10/110 Proprietary mortar J31/130 Inverted roof coating Q37/110 Intensive green roof Q37/130 Extensive green roof Q37/310 Inverted roof insulation |
Product range |
Third party product certification | BDA Agrément® BAB 18-026-P-A-UK. |
Adhesion to concrete | ≥ 0.8 MPa BS EN 1542. |
TensileStrength | Ambient: 0.5 MPa BS 6319-7:1994. Immersed: 0.4 MPa BS 6319-7:1994. |
Elongation | Ambient: 120 - 130 % manufacturer test. Immersed: 70 - 80 MPa manufacturer test. |
Loading capability – 28 days | 8 to 10 MPa BS 4551. |
Hardness | 84.0 Shore A BS EN ISO 868:2003. |
Water permeability coefficient | 5.37 x 10-16 m/sec DIN 1048 Part 1. |
Water vapour diffusion resistance | Sd value: 1.55 m BS EN ISO 7783-2. µ value: 775 µ. 7.75 MNs/g. Manufacturer guidanceCalculation from Sd value. |
Water resistance | Positive side: 10.0 Bar DIN 1048. Negative side: 1.50 Bar DIN 1048. |
Reaction to fire classification | Euroclass Bs1, d0 BS EN 13501-1. |
UV resistance | Stable but will discolour, 50 years UNI EN ISO 11507:2007. |
pH | 12. |
Thickness | 2 mm. |
Odour | Low (polymeric). |
Volatile organic compounds (VOC) content | 1.76 g/L (0 when cured). |
Capacity | 30 kg in two parts - 10 kg Part A (Powder) and 20 kg Part B (Liquid). |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Cementitious Guidance for specification option: Cementitious flexible waterproofing membrane. |
Recyclability | 0 |
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
Platform | Compatible | Version |
---|---|---|
![]() | Revit 2015 | 4 |
![]() | IFC2X3 | 2 |
