WallBeam® Fire-Rated - Fire-Proof Structural Support Beam

WallBeam is a innovative structural support system. This support beam that gives more than 120 minutes of vertical and horizontal fire stopping and provides a suitable product for supporting riser partition walls.

Replaces the need for the use of secondary steel beams which require subsequent fireproofing works to achieve compliance. This is costly, labour intensive and brings an additional layer of risks to the construction project from working at height, coordination of trades, rework because of site damage and potential programme delays.

The design incorporates the AlphaRiser channel profile and therefore enables full compatibility with the GRP support joists of lateral accommodation of additional WallBeams.

Features and benefits:

• Provides over 120 minutes of fire resistance, tested to BS EN standards.
• Compatible with AlphaRiser channels for easy integration with GRP joists.
• Maintains fire safety without additional boarding, saving time and cost.
• Maximizes usable riser space with a compact design.
• Constructed from laser-cut mild steel with lightweight concrete infill for strength.
• Standard load capacity of 5 kN per linear metre, with higher capacities available on request.
• Slim 160 mm width and variable heights (200–300 mm) to suit spans up to 5 m.
• Allows flexible positioning along AlphaRiser channels for simple site tolerance.
• Durable materials ensure long service life and structural reliability.
• Supports partition walls, floor joists, and services in one integrated solution.
