Description

The ancillary cancel plate is used to cancel the alarm; it is used in applications that require multiple cancel plates. It is used to supplement the standard cancel plate for example by the shower in an accessible bathroom. It does not have indication or a buzzer thus it consumes less power. It should be mounted 1m from the floor and level with the front of the toilet. The cancel plate is built in a single gang brushed stainless steel plate as standard.

For simplicity all wiring is a standard two core cable, the wiring order of the plates is not fixed and therefore can be wired in any order to give total flexibility in the installation routes.

General information
Features

Compact design, braille enhanced cancel button

Finish

Brushed

Material

Stainless steel

Size

86 x 86 x 22 mm

Uniclass 2015
Assistance call reset units (Pr_75_75_04_05)Primary
Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
- 1 2.1
Download now from NBS National BIM Library
