VertiTex II - Vertical Awning for Sun Protection
Verified by manufacturer 6 days ago
VertiTex II Zip
VertiTex II Zip
Vertical awning offering sun protection, prevents the patio and indoors from becoming uncomfortably hot and provides visual privacy.
Application
Sun protection, temperature moderation and visual privacy. Can be installed on walls, ceilings or jambs.
Suitable for difficult facades and easily retrofittable.
Description
Vertical awning offering sun protection, prevents the patio and indoors from becoming uncomfortably hot and provides visual privacy.
Three versions available:
- VertiTex Zip: the wind-resistant version.
- VertiTex Rail: the universal version.
- VertiTex Rope/ Intended Rope: the light version.
Features and benefits:
- Thanks to the patented OptiFlow system®, the cassette even looks very small and subtle with very large fabrics up to 6 m wide.
- VertiTex II can be flexibly and subtly mounted on the patio roof thus providing reliable all-round protection, even with a low-lying sun and wind.
- Vertical privacy and sun protection on balconies.
- Suitable alternative to external shading systems or roller shutters.
- Transparent fabric option.
- Modern design,
- Elegant design faceplate.
- High wind resistance: copes easily with winds up to force 5 on the Beaufort scale, the Zip version even manages up to WF 6.
General information
Color | Beige Black Blue Bronze Brown |
Finish | Textured |
Material | Metal Fabric |
Shape | Rectangle Square |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | B91/370 Pergola/ arbour B91/330 Canopy |
Specification data - Awnings
Standard | To DIN 13561 |
Size (width x depth) | Guidance for specification option: Insert requirements:
Maximum shadeable area: 15 m². Manufacturer guidanceMulti-section units also available. |
Frame | |
Format | Retractable. |
Material | Manufacturer's standard. Manufacturer guidanceSee also Frame colour/ finish below. |
Canopy | |
Material | screens by weinor® StarScreen. Guidance for specification option: Maximum system height: 3000 mm. my collections 2. Guidance for specification option: Maximum system height: 2200 mm. screens by weinor® fibreglass screen. Guidance for specification option: Maximum system height: 3000 mm. |
Colour and pattern | Guidance for specification option: Consult manufacturer's literature for options and insert requirements. |
Headrail | |
Material | Cassette type 92, square (101 x 92 mm). Guidance for specification option: Standard. Cassette type 92, round (101 x 92 mm). Guidance for specification option: Standard. Cassette type 112, square (121 x 112 mm). Cassette type 112, round (121 x 112 mm). |
Colour | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Operation | |
Mode | Electrically powered, VertiTex II motor drive. Electrically powered, VertiTex II motor drive, with remote control. Guidance for specification option: Consult manufacturer for remote control options and insert requirements. |
Power supply | Guidance for specification option: Consult manufacturer for requirements and insert details. |
Operating effort | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Mechanism endurance | Manufacturer's standard. Guidance for specification option: Consult manufacturer for details. |
Wind resistance | To DIN 13561, class 3. Guidance for specification option: Wind force 6 on the Beaufort Scale (up to 49 km/h). |
Frame colour/ finish | Guidance for specification option: Consult manufacturer's literature for options and insert requirements. Choose from:
|
Sustainability data
Country of product manufacture | Germany |
Material | Metal Fabric |
