Verge U - Universal Dry Fix Verge Units

Verified by manufacturer 24 days ago

EASYVERGEU/BLK

Easy-Trim Roofing and Construction Products Ltd Variant:

A robust, weatherproof verge system that eliminates the need for wet mortar bedding and left and right-handed pieces.

Jump to:
01282 930680 Website

Application

  • Suitable for use with most tile types, but not for use with slates or high-profiled tiles.
  • Suitable for pitches between 15 – 55 degrees.
  • Suitbale for use in new builds or refurbishment projects.

Description

The units are universal meaning they can be used on the left and right side of the roof verge, resulting in a faster installation. Strong holding capabilities ensure tiles are held securely in place without becoming vulnerable to wind dislodgement.


Features and Benefits:

  • Universal handed units suitable for use on both sides of the roof.
  • Tight secure fix, not vulnerable to wind dislodgement.
  • Flexible polypropylene material allows for rapid installation.
  • Can be installed in any weather condition.
  • Weather resistant and UV-stable.
  • Excellent UV and colour stability, no fading or unsightly staining on soffits.
  • Manufactured in-house, in the UK.


Quality Standards:

  • Conforms to BS 5534:   Slating & Tiling for Pitched Roofs & Vertical Tiling.
  • Conforms to BS 8612:   Dry Fixed Ridge, Hip & Verge Systems for Slating & Tiling.

General information

Color

Black

Brown

Grey

Red

Guidance for specification option:

Terracotta

Material

Polypropylene

Shape

Trapezoid

Guidance for specification option:

Isosceles trapezoid.

Length

410 mm

Width

165 mm

Height

50 mm

Warranty description

20 year

Uniclass

Pr_35_90_93_30 Dry fixing vergesPrimary

CAWS

H61/405 Dry (closed) verges

H61/50 Dry (closed) verges

H65/405 Dry verges

H65/50 Dry verges

H67/335 Verge caps

H67/40 Verges

Product range

Dry Fix Solutions

Specification data - Dry fixing verges

Accessories

Verge units.

Ridge caps.

Starter and end packs.

Colour

Black.

Sustainability data

Contains Red List materials

No

Country of material origin

United Kingdom

Country of product manufacture

United Kingdom

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

100 %

Literature

Universal Dry Fix Verge Datasheet

Universal Dry Fix Verge Datasheet

Dry Fix Universal Verge Installtion Guide

Dry Fix Universal Verge Installtion Guide
