NBS Source

Urban Myth – Carpet Tile & Plank

Gradus

A textured loop pile carpet available in both tile and plank format.

Jump to:
+44 (0)1625 428922 Website

Application

Urban Myth is suitable for commercial office and education applications.

Description

Urban Myth is a textured loop pile carpet available in both tile and plank format. The random design offers versatility and the opportunity to create innovative and exciting floor schemes. The range includes a choice of complementary colours comprising six grey base tones and six vibrant accent colours that can be combined to create stunning installations.


Features and benefits:

  • Antron® Lumena™ Solution Dyed Nylon 6.6 surface yarn provides inherent stain resistance and colourfastness, and outstanding soil resistance and durability.
  • 12 complementary colour references for both tile and plank formats offering design choice.
  • Colours can be combined to create a coordinated floor scheme
  • Suitable for creating zones, feature areas and transitions across the floor.
  • A wide range of installation methods offering design versatility.
  • 23 dB impact noise rating – Improves acoustic performance by reducing impact noise.
  • BREEAM A+ or A rated across all BREEAM defined building applications against which it has been assessed.


Installation and maintenance:

  • All carpets should be installed in accordance with the BS 5325:2001 Code of practice for installation of textile floor coverings.
  • Recommended adhesive: F. Ball & Co. Ltd, Product code: F41.
  • Installation methods: Tiles – Quarter Turn, Brick Bond and Random / Planks – Half Drop, Random Drop, Herringbone and Double Herringbone.
  • Installation and maintenance instructions are available.

General information

Color

Other

Material

Nylon

Surface yarn: 100% Antron® Lumena™ Solution Dyed Nylon 6.6.

Length

500 mm

Tile.

1000 mm

Plank.

Width

250 mm

Plank.

500 mm

Tile.

WarrantyDescription

Twelve year wear and Ten year anti-static warranties (full details on request).

-

Uniclass

Pr_35_57_11_62 Pile carpet tilesPrimary

CAWS

M50/15 Carpet tiling

M50/130 Carpet tiling

Specification data - Pile carpet tiles

Style

Tufted loop pile.

Material

100% Antron® Lumena™ Solution Dyed Nylon 6.6.

Surface Yarn.

Classification

-

Standard

To BS EN 1307.

Third-party certification

CE marked and manufactured to EN 14041. BREEAM A+ or A rated across all BREEAM defined building applications against which it has been assessed.

Level of use class

To BS EN 1307, Class 33.

Size

500 x 500 mm.

Tile.

250 x 1000 mm.

Plank.

Colour and pattern

07301 Quartz.

LRV 20.78.

07302 Pewter.

LRV 11.74.

07303 Steel.

LRV 11.29.

07304 Lead.

LRV 6.02.

07305 Graphite.

LRV 5.98.

07306 Carbon.

LRV 2.43.

07307 Citrine.

LRV 14.26.

07308 Amber.

LRV 12.98.

07309 Peridot.

LRV 13.44.

07310 Sapphire.

LRV 6.13.

07311 Amethyst.

LRV 6.49.

07312 Ruby.

LRV 6.99.

Total carpet thickness

6 mm.

Total weight

4110 g/m².

Pile weight

650 g/m².

Surface material

100% Antron® Lumena™ Solution Dyed Nylon 6.6.

Gauge

1/12".

47.2 per dm.

Primary backing

Non-woven.

Secondary backing

Bitumen.

Static electricity

<2 kV.

To ISO 6356 Static electrical propensity.

Castor chair rating

Pass.

To BS EN 985 Test A.

Impact sound reduction

23 dB.

To EN ISO 10140-3

Flammability

Class Bfl-s1.

To BS EN 13501-1.
