Up and Over Canopy – Steel - Garage Door

Verified by manufacturer 5 months ago

Manual Operation

Garador Ltd Variant:

Up and over canopy garage doors.

Jump to:
+44 (0)1935 443722 Website

Application

Suitable for garage door openings.

Description

Classic and modern steel up and over canopy garage doors available in a variety of styles.


Features and benefits:

  • Low maintenance and long lasting.
  • Safe and reliable.
  • Tough and sturdy construction.
  • Requires less space for opening but one-third of the door protrudes from the garage while open.
  • Quick fitting with just seven fixings with steel frame.
  • Single door sizes available up to 2439 x 2136 mm.
  • 60 mm frame standard.
  • Option of panel door design.
  • Powder-coated finish in a range of colours.

General information

Color

White

Green

Black

Blue

Brown

Show more

Finish

Powder-coated

Material

Steel

Shape

Rectangle

Width

2134 mm

2284 mm

2439 mm

Height

1981 mm

2036 mm

2136 mm

Warranty description

Ten year

Guidance for specification option:

Ten year limited warranty.

Uniclass

Pr_30_59_24_93 Up-and-over doorsetsPrimary

CAWS

L20/60 Doors

L20/680 Up-and-over garage doors

Specification data - Up-and-over doorsets

Arrangement

One piece canopy up and over.

Door

-

Material

Steel.

Finish

Polyester powder-coated.

Operation

-

Activation

Manual.

Accessories

Garage door frame.

Guidance for specification option:

60 mm frame standard.

Colour

Traffic White (RAL 9016).

Moss Green (RAL 6005).

Jet Black (RAL 9005).

Pigeon Blue (RAL 5014).

Terra Brown (RAL 8028).

Show more

Door design

Carlton.

Horizon.

Sailsbury.

Sutton.

Ascot.

Show more

Manufacturer guidance

Consult manufacturer's literature for details.

Structural opening size

2134 x 1981 mm.

Guidance for specification option:

Overall outer frame size: 2244 x 2039 mm.

2134 x 2036 mm.

Guidance for specification option:

Overall outer frame size: 2244 x 2094 mm.

2134 x 2136 mm.

Guidance for specification option:

Overall outer frame size: 2244 x 2194 mm.

2284 x 1981 mm.

Guidance for specification option:

Overall outer frame size: 2394 x 2039 mm.

2284 x 2036 mm.

Guidance for specification option:

Overall outer frame size: 2394 x 2094 mm.

Show more

Manufacturer guidance

Internal frame size.

Width x height.

Arrangement

Behind brickwork.

Between brickwork.

Sustainability data

Country of product manufacture

United Kingdom

Material

Steel

Literature

Garador - Guide to Garage Door Specification

Garador - Guide to Garage Door Specification
