UltraClear™ Float Glass
Application

  • Architectural façades.
  • Partitions, shop fronts and show cases.
  • Floors, stairs and balustrading.
  • Table tops, shelves, consoles and folding screens.
  • Residential insulating glass units.
  • Laminated safety glass.
  • Silk-screen printed glass.
  • Mirrors.
  • Transportation

Description

Guardian Float Glass is perfectly flat and has virtually parallel surfaces. Automatic cutters are used to trim the glass into sizes which can be shipped or handled for further processing.

Further processing:

  • Toughening.
  • Heat soaking.
  • Heat strengthening.
  • Laminating.
  • Drilling.
  • Notching.
  • Bending.
  • Edgeworking.
  • Brilliant cutting.
  • CNC shaping.
  • Screen-printing.
  • Leaded and Decorated.
  • Manufacture into suitable single, double or triple glass insulating units.

Applications:

  • Architectural façades.
  • Partitions, shop fronts and show cases.
  • Floors, stairs and balustrading.
  • Table tops, shelves, consoles and folding screens.
  • Residential insulating glass units.
  • Laminated safety glass.
  • Silk-screen printed glass.
  • Mirrors.
  • Transportation

Standards:

Guardian Europe has ISO 9001 accreditation for the manufacture of float glass at all of its European based float glass plants. Guardian float glass complies with the requirements of EN 572-2: 1994 'Glass in Building - Basic soda lime silicate glass products -2: Float glass'. Guardian also has ISO 14001 Environmental Management System standard.

General information
Features

Low iron oxide content giving higher transparency and natural, colour

Material

Float Glass

Uniclass 2015
Pr_25_71_33_37 Heat-strengthened glass sheetsPrimary
CAWS

L40/310 Bead-fixed single-glazing

L40/370 Bead-fixed insulating glass units

L40/330 Bead-fixed single-glazing

L40/350 Bead-fixed single-glazing

L40/380 Bead-fixed insulating glass units

L40/55 Bead-fixed insulating glass units

L40/381 Bead-fixed insulating glass units

L40/210 Putty-fronted single-glazing

L40/230 Bead-fixed single-glazing

L40/58 Bead-fixed insulating glass units

L40/371 Bead-fixed insulating glass units

L40/250 Bead-fixed single-glazing

L40/372 Bead-fixed insulating glass units

L40/470 Zipper gasket glazing

H13/115 Structural glass assembly

L40/260 Bead-fixed single-glazing

L40/430 Single-glazing into grooves

L40/410 Single-glazing into grooves

H10/115 Patent glazing

L40/57 Bead-fixed insulating glass units

L40/40 Putty-fronted single-glazing

L40/530 Internal tape glazing

H10/10 Patent glazing

L40/90 Internal tape glazing

L40/50 Bead-fixed single-glazing

L40/490 Single-sided gasket glazing

L40/450 Single-glazing into grooves

H11/110 Curtain walling

Specification data - Heat-strengthened glass sheets
Product Reference

ExtraClear Float Glass

UltraClear Float Glass (Low Iron)

Thickness

2 mm

3 mm

4 mm

5 mm

6 mm

8 mm

10 mm

12 mm

15 mm

Standard product features

Size:

- Manufacturer's standard (other sizes available):

  • Jumbo: 3210 x 6000 mm.
  • Split: 3210 x 2250–2550 mm.

Product Options

ExtraClear:

ExtraClear float glass is Guardian's standard clear float glass offering, unlike most other clear float glass Guardian's ExtraClear has a reduced iron content, this product sits half way between normal clear float and Low Iron glass and provides a better level of clarity with less discolouration (blue/green appearance) when viewed from the cut edge of the glass.

UltraClear:

Low Iron float glass which has an almost crystal like appearance, the edge detail is almost completely clear with little to no blue/green discolouration.

Digital objects
PlatformCompatibleVersionCertified to
IFC
IFC2X3 3 1.3
Revit
Revit 2016 4 2.0
Download now from NBS National BIM Library
