Tubular Heater - ECOT Range
Description

Low output, adjustable heat source suitable for a huge range of applications, from airing cupboards to shop windows and greenhouses. Includes one-year warranty.

Features:

  • Full range of six sizes/ outputs.
  • Discreet mounting brackets for walls or floors.
  • Reversible left or right hand cable entry.
  • IPX4 rated.
  • Even heat distribution across heater body.

General information

Color

White, grey

Size

408 x 80 x 83 mm

Uniclass 2015

Pr_70_60_36_74 Room heatersPrimary

CAWS

T90/465 Radiators

T90/61 Radiators

Specification data - Room heaters

Product Reference

ECOT1FT

408 mm long, 40 W output.

ECOT2FT

713 mm long, 80 W output.

ECOT3FT

1018 mm long, 120 W output.

ECOT4FT

1323 mm long, 160 W output.

ECOT5FT

1630 mm long, 200 W output.

ECOT6FT

1933 mm long, 240 W output.

Standard product features

Size (h x d):

81 x 80 mm.

Colour:

White/ grey.

Thermostat:

Bimetallic with rotary control.

Thermal cut-out:

Automatic reset.

Element type:

Coiled.

Weight:

  • ECOT1FT: 0.5 kg.
  • ECOT2FT: 0.6 kg.
  • ECOT3FT: 0.8 kg.
  • ECOT4FT: 1 kg.
  • ECOT5FT: 1.1 kg.
  • ECOT6FT: 1.3 kg.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2016 2 2.0
IFC
IFC2X3 1 1.3
Download now from NBS National BIM Library
