BBA Agrément Certificate
Truegrip BT is a high friction surfacing system meeting the demanding requirements of a BBA/HAPAS Type 1 approved anti-skid surfacing for external applications.
Conren Truegrip High-Friction Surfacing System comprises a two-component modified epoxy binder and a graded (1mm to 3mm) calcined bauxite aggregate. The system is available in three grades:
Hot applied – suitable for machine application to bituminous surfaces
Handlay BT – suitable for hand mixing and laying to bituminous surfaces
Handlay EP – suitable for hand mixing and laying to concrete surfaces
Conren Truegrip High-Friction Surfacing System is satisfactory for use as a high-friction surfacing on highways with surface texture depths of between 0.5 and 2.0mm, measured using the sandpatch test as defined in BS 598-105: 1990.
The system is classified as Type 1, in accordance with the results of the performance tests as defined in Table 1 of the Guidelines Document for the Assessment and Certification of High Friction Surfaces for Highways.
Installation of the Conren Truegrip High-Friction Surfacing System must be carried out by BBA approved installers under the Assessment and Surveillance Scheme for Installers of High-Friction Surfaces for Highways.
Provides an anti-skid barrier for external bituminous or concrete surfaces
Coloured aggregates are available dependant on what is specified
Anti-skid, fast cure, durable
Epoxy resin and aggregate
All warranties provided are based on each individual project - dependant on environmental and maintenance factors
Q22/10 Asphalt concrete paving
Q22/15 Asphalt concrete paving
Q22/365 Proprietary surface treatment
Truegrip hot applied
suitable for machine application to bituminous surfaces.
Truegrip handlay BT
suitable for hand mixing and laying to bituminous surfaces.
Truegrip handlay EP
suitable for hand mixing and laying to concrete surfaces.
Refractory grade PSV 70 calcined bauxite
Standard product features
Flexible, high friction anti-skid, high visibility. Consistent quality.
Resistant to petrol, diesel, chemicals and salt. Resistant to abrasion.
Health and safety:
Very low fume installation.
Several standard lead free colours are available, lead-based yellow is also available.
Calcined bauxite is the standard aggregate. Other decorative aggregates can also be used.
1–3 mm used for roads, 0.5–1.4 mm for pedestrian areas.
