Truegrip BN

Truegrip BN

Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Conren Ltd

A high performance, resin bonded system intended for professional use in external applications, providing a decorative and anti-skid resurfacing system for highways, driveways and footpaths.

Jump to:
+44 (0)1978 661991 www.conren.com
Description

Conren Truegrip High-Friction Surfacing System comprises a two-component modified epoxy binder and a graded (1mm to 3mm) calcined bauxite aggregate. The system is available in three grades:

Hot applied – suitable for machine application to bituminous surfaces

Handlay BT – suitable for hand mixing and laying to bituminous surfaces

Handlay EP – suitable for hand mixing and laying to concrete surfaces

Conren Truegrip High-Friction Surfacing System is satisfactory for use as a high-friction surfacing on highways with surface texture depths of between 0.5 and 2.0mm, measured using the sandpatch test as defined in BS 598-105: 1990.

The system is classified as Type 1, in accordance with the results of the performance tests as defined in Table 1 of the Guidelines Document for the Assessment and Certification of High Friction Surfaces for Highways.

Installation of the Conren Truegrip High-Friction Surfacing System must be carried out by BBA approved installers under the Assessment and Surveillance Scheme for Installers of High-Friction Surfaces for Highways.

General information

Size

0.5–1.4 mm

1–3 mm

Finish

Provides an attractive, durable, anti-slip finish with a high resistance to petrol, diesel, chemicals and salt

Color

Coloured aggregates are available dependant on what is specified

Features

Anti-skid, fast cure, durable

Material

Epoxy resin and aggregate

WarrantyDescription

All warranties provided are based on each individual project - dependant on environmental and maintenance factors

Uniclass 2015

Pr_35_31_05_71 Resin-bound mixed aggregate surfacingsPrimary

CAWS

Q22/10 Asphalt concrete paving

Q22/15 Asphalt concrete paving

Q22/365 Proprietary surface treatment

Specification data - Resin-bound mixed aggregate surfacings

Product Reference

Truegrip hot applied

suitable for machine application to bituminous surfaces.

Truegrip handlay BT

suitable for hand mixing and laying to bituminous surfaces.

Truegrip handlay EP

suitable for hand mixing and laying to concrete surfaces.

Binder

-

Binder colour

Blue

Buff

Green

Red

White

Yellow

Aggregate

Refractory grade PSV 70 calcined bauxite

Standard.

Size

0.5–1.4 mm

1–3 mm

Standard product features

Surface:

Flexible, high friction anti-skid, high visibility. Consistent quality.

Durability:

Resistant to petrol, diesel, chemicals and salt. Resistant to abrasion.

Health and safety:

Very low fume installation.

Product Options

Binder:

– Colour:

Several standard lead free colours are available, lead-based yellow is also available.

Aggregate:

Calcined bauxite is the standard aggregate. Other decorative aggregates can also be used.

– Size:

1–3 mm used for roads, 0.5–1.4 mm for pedestrian areas.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2016 4 2.0
IFC
IFC2X3 2 1.3
Download now from NBS National BIM Library
