Traditional Timber Sliding Box Sash Window – Heritage range - Timber Sash Windows
Verified by manufacturer 4 months ago
Heritage Single Glazed
Heritage Single Glazed
British Woodworking Federation
Certificate type
Health & Safety Accreditation
Certificate type
Timber cord hung sash windows for listed buildings.
Application
Replacement timber sash windows for listed buildings and conservation areas.
Description
The Traditional Timber Sliding Box Sash Window Heritage range has been designed to meet the needs of listed buildings, helping to improve energy efficiency while retaining the traditional character of the property.
The windows replicate as closely as possible the proportions and designs of historic sash windows, whilst incorporating the latest manufacturing techniques.
The Sash Window Workshop windows have a minimum service life of 60 years if properly maintained.
Features and benefits:
- Available with single or double glazing (non-Document L) and a range of glazing bars.
- All windows comply with the European manufacturing standard EN 14351 and European glazing standard EN 1279.
- FSC certification for 100% of the timber used.
- All the processes in the manufacture and installation of the windows are controlled in-house.
- The windows have a minimum service life of 60 years if properly maintained.
- UKCA marked.
General information
Color | White Other |
Finish | Painted |
Material | Wood |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | 50 year Guidance for specification option: Joinery guarantee. Consult the manufacturer's Supply Only Warranty and Supply and Install Warranty and Maintenance Guide for details. |
Uniclass | |
CAWS | L10/10 Wood windows L10/210 Wood windows |
Specification data - Wood window units
Standard | To EN 14351. |
Dimensions and configurations | Manufacturer guidanceBespoke sizes and configurations; refer to a drawing or schedule. |
Frame | |
Profile | Ovolo.Lambs tongue. |
Wood species | Accoya/ Tricoya. |
Chain of custody | FSC. |
Finish as delivered | 3 no. coats of factory applied Sigma white semi gloss paint, 2 no. |
Ventilator | Not required.Concealed in frame head. |
Frame horns | No horn.90 mm Victorian horn.70 mm short Victorian horn.Bespoke horn detailing. |
Glazing or infill | |
Standard | Relevant parts of BS EN 1279. |
Requirements | Single glazed.Guidance for specification option: Maximum thickness 8.8 mm. Consult manufacturer for glass options. |
Hardware | 4 no. pulley wheels, I no. fitch catch, 2 no. sash lifts, 1 no. rola lock set.Guidance for specification option:
|
Operation | |
Type | Manual. |
Weather seal (factory applied) | Full weatherstripping (Aquamac 48) integrated into the sashes frames and beading. |
Glazing bars | 16 mm Ovolo. 20 mm Ovolo. 24 mm Ovolo. 30 mm Ovolo. 35 mm Ovolo. |
Staff bead | Standard. Special. Guidance for specification option: (POA) |
Sustainability data
Contains Red List materials | No |
Country of material origin | New Zealand |
Country of product manufacture | United Kingdom |
Material | Wood |
Third party certifications
British Woodworking Federation
British Woodworking Federation Membership
Health & Safety Accreditation
SafeContractor Certificate
