Application

Suitable for use within roofing systems where horizontal and vertical substrates or building materials meet. The trapezium-shaped profiles allows the product to be easily pressed into corners and curves, serving as a support for the subsequent waterproofing membranes.

Description

Bituminous, flexible, cold applied angle fillet with a trapezium-shaped profile.

Features and benefits:

  • Flexible, versatile material.
  • Simple application.
  • Cold applied.
  • Supports subsequent roofing membranes.
  • Suitable for use where horizontal and vertical substrates meet.
  • CE marked.

Applications:

Suitable for use within roofing systems where horizontal and vertical substrates or building materials meet. The trapezium-shaped profiles allows the product to be easily pressed into corners and curves, serving as a support for the subsequent waterproofing membranes.

General information
Size

Length: 6.25 m (± 5 %)

Width: 46 mm (± 5 %)

Uniclass 2015 Angle fillets (Pr_35_90_07_04)
Specification data
Product Reference

TN TEK Bitumen Wedge

Standard product features

Size:

  • Length: 6.25 m (± 5 %).
  • Width: 46 mm (± 5 %)

Weight of roll:

5.5 kg.

Technical characteristics:

  • Thickness: 18 mm (±5%).
  • Density: 1.3 g/m³.
  • Softening point (ring and ball): 105°C.
  • Finish of top side: Foil.
