Thermally insulated aluminium bi-fold door system - ASS 70 FD
Verified by manufacturer 13 days ago
Thermally insulated bi-fold system.
Application
Suitable where there is a need for quiet running and outstanding weathertightness.
Description
Thermally insulated bi-fold system with narrow face widths and weathertightness for use in outdoor areas. Design options include matching flat door handles and a 90° corner with a flat, thermally insulated threshold for barrier-free access. The flexible and quiet vent stacks can be folded to the right, left, inwards or outwards as required.
Features and benefits:
- Flat threshold with rebate gasket allows easy access.
- Watertight and burglar resistant.
- Outer and vent frames are mitre cut on all corners.
- High degree of flexibility for large-scale projects due to option for customer to roll profiles together.
- Structural expansion profile allows for subsequent adjustment of the top outer frame.
- Magnetic retaining catch with an elegant design.
Standards:
- DIN EN 12210.
- DIN EN 12208.
- DIN EN 12207.
- DIN EN 13115.
- DIN V ENV 1627.
- DIN EN 1007.
General information
Color | Manufacturer guidanceProfile design in more than one colour, consult manufacturer. |
Material | Aluminium |
Uniclass | |
CAWS | L20/60 Doors L20/520 Sliding doors |
Specification data - Sliding door and partition sets
Arrangement | Bi-fold opening. |
Operation | Manual.Guidance for specification option: Push, pull. |
Execution | Installing hardware. |
Product Reference | ASS70FD Inward Opening Folding Sliding Door ASS70FD Outward Opening Folding Slding Door |
Wind load resistance | To EN 12210, B3/C3. |
Watertightness | To EN 12208, Class 8A/9A. |
Air permeability | To EN 12207, Class 3. |
Operating forces | To EN 13115, Class 4. |
Secured By Design | To ENV 1627, Class 2. |
Depth | 70 mm. |
Thickness | 6–45 mm. |
Face width | From 120 mm. |
Weight | Up to 100 kg. Guidance for specification option: Depending on the design. |
Size: | 3.6 m². Guidance for specification option: Depending on the design. |
Sound reduction | Up to class 4. |
Durability | Up to 1 million cycles. |
Sustainability data
Country of material origin | United Kingdom |
Material | Aluminium |
