Theano Free-standing Bath UBQ155ANH7F2BCV
Verified by manufacturer 9 months ago
UBQ155ANH7F2BCV - Stone white
UBQ155ANH7F2BCV - Stone white
Free standing bath.
Description
Free standing bath
Features and benefits
- Duo.
- In accordance with DIN 1986-100, a floor drain is required to protect the building against flooding, if a bath is installed without an overflow. No floor drain is required if ViFlow is used.
- Push-to-Open valve without overflow function and ViFlow.
General information
Color | White |
Material | Quaryl® |
Length | 1550 mm |
Width | 480 mm |
Uniclass | |
CAWS | N13/355 Baths N13/35 Baths |
Specification data - Baths
Form | Free-standing. |
Materials | Quaryl®. |
Colour | Stone white. |
Size | 1550 x 750 x 480 mm. |
Volume to overflow (maximum) | 250 L. |
Water supply, overflow and waste holes | |
Water supply | No tap holes. |
Overflow | No overflow hole. |
Waste | Bottom waste outlet. |
Integral accessories | ViFlow.Multifunction cushion. |
Anti-slip finish | Class A. |
Weight | 49.4 kg. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 OBJ | - | 1 |
 Revit | - | 1 |
 ARCHICAD | - | 1 |
 3Ds Max | - | 1 |
 IFC | - | 1 |
 SketchUp | - | 1 |
