Suitable for all nominally flat roof constructions and coverings e.g. Single Ply PVC, Fiberglass, lead, copper, zinc and other standing seams and asphaltic material.

Suitable for Green / Sedum Roofs

Features and Benefits:

  • Grade 6063-T6 Extruded Aluminium
  • Fully Thermally Broken
  • Polyester Powder Coating to Minimum 60 Microns
  • Suitable for Marine / Coastal Environments
  • Stainless Steel Concealed Fixings
  • Air permeability – Class 4 ±900 pascals
  • Watertightness – Class E1050 pascals
  • Wind resistance – Class C5 ±2000 pascals
    serviceability ±3000 pascals safety
  • Controlled by wall-mounted touch screen
  • Can be controlled remotely by app on smart device

Wide range of sizes available:
Up to 8000 mm (external Width) in the sliding direction
Up to 4000 mm (external Span) down the fall

Glazing Details:
6 mm Toughened Outer
20 mm Warm Edge Spacer with 90% Argon Cavity
6mm Toughened Low-e Inner
Glass Centre Pane U-Value 1.1W/m²

Internal – Ral 9010 Mat
External – Ral 7015 Mat

General information

Any RAL or BS colour can be specified anodised options


Non standard sizes available on request, fully thermally broken, suitable for coastal and marine environments, controlled by all mounted or remote smart touch screen device, wide range of sizes available on request


Polyester powder coating


Stainless steel




4000 x 8000 mm

Uniclass 2015
Framed rooflights (Pr_30_59_72_31)Primary
