Tessera Arran Carpet Tile
Application

Internal use, all busy commercial and public sector locations.

Description

Multi-height, textured loop pile carpet tile with irregular peaks and furrows, which deliver a tactile, linear design.

Features and benefits:

  • Investment in an extruder has reduced bitumen usage by 50%.
  • Method of laying: broadloom, brick, quarter-turn or tessellated.
  • Made with 100% renewable electricity.
  • Each tile features a carefully blended duo of yarns, 100% solution-dyed to ensure that the subtle colour contrasts are maintained throughout the lifespan of the flooring, even in the most demanding environments subjected to intensive cleaning regimes.
  • Carpet tiles have irregular peaks and furrows which deliver a tactile, linear design.
  • Also available in SOFTbac® secondary backing.

Method of laying:

Broadloom, quarter turn or tessellated.

Application:

Internal use, all busy commercial and public sector locations.

Adhesive:

542 Eurofix Tack Plus solvent free release system.

General information
Finish

Low level loop carpet tile

Color

Barley

Dove

Java

Kiwi

Spa

Olive

Umber

Espresso

Latte

Damask

Danuble

Thistle

Coffee

Noir

Heather

Hessian

Mineral

Rice

Shape

Square

Size

500 mm x 500 mm

Uniclass 2015
Pr_35_57_11_62 Pile carpet tilesPrimary
CAWS

M50/130 Carpet tiling

M50/15 Carpet tiling

Specification data - Pile carpet tiles
Product Reference

Tessera Arran carpet tiles

Standard

BS EN 1307 & 14041

Level of use class

Class 33; Heavy Contract

Total thickness

7 mm ± 10%

Height

4 mm ± 0.5 mm

Pile composition

100% Invista Antron® Lumena polyamide

Dye method

100% solution dyed

Stitch density

202960 per m2 ± 10%

Weight -
Pile weight after shearing

950 g/m² ±10%

Total weight

4455 gsm ± 10%

Backing -
Primary

Polyester/ Polymide

Secondary

Modified bitumen and polyester fleece- standard

SOFTbac®

Castor chair use (to BS EN 985)

Minimum R value: ≥2.4

Light fastness (to BS EN ISO 105 B02)

≥5

Dimensional stability (to BS EN 986)

≤0.2%

Impact sound reduction

23 dB

Ska Rating

Meets Ska Rating Criteria for M12 soft floor coverings in both office and retail schemes

Colour and pattern

Not required

1502 Danube

1515 Latte

1509 Noir

1512 Dove

1521 Golden sand

1523 Dusky green

1518 Foggy day

1519 Stone wall

1522 Shallow water

1520 Driftwood

1525 Mountain mist

1524 Moss tone

Reaction to fire (to EN 13501-1)

BfI-s1

Slip resistance (to EN 13893)

DS: ≥0.30

Electrical resistance -
Static dissipative (to BS ISO 10965):

<1 x 109 Ω

Body Voltage (to EN 1815)

Pass (< 2kV)

Standard product features

Colour:

Twelve colour options available.

Feature:s

Also available in SOFTbac® carpet tile backing, an additional backing layer which acts as an underlay and offers increased sound and thermal insulation.

Finish:

Tufted multi-height loop pile carpet tile.

Material:

Manufactured from 100% solution dyed Invista Antron® Lumena polyamide, on a modified bitumen polyester primary and secondary backing.

Shape:

Tile.

Size:

500 x 500 mm - As standard, other sizes are available to special order.

Warranty description:

Standard backing: 10 years; SOFTbac® backing: 15 years.

Recycled content:

57.29%.

Recyclability:

100%.

Embodied carbon:

25.9 Kg Co2 Eq /m2.

Red listed materials:

None.

Country of origin:

UK.

Environmental information
Embodied carbon

25.9 Kg Co2 Eq /m2

Recyclability

100%

Recycled content

57.29%
