Taralay Impression Compact - Sheet - Wood - Vinyl Flooring

Verified by manufacturer 3 months ago

1093 - CHARME KRAFT

Gerflor Flooring UK Limited Variant:
Third party certifications:
  • EPD

    EPD

    Certificate type

Multi-layered construction, compact vinyl sheet floor covering for high traffic applications.

Jump to:
BOS
01625 428 922 Website

Application

Taralay Impression Compact is a commercial floorcovering suitable for healthcare, education, commercial and public areas.

Description

Taralay Impression Compact is a multi-layered construction, compact vinyl sheet floor covering with 0.7 mm wear-layer and patented Protecsol® 2 surface treatment. It requires no wax for life, delivering ease of maintenance and energy savings. Designed for normal to high traffic applications it comprises a compact backing, reinforced with a glass fibre veil and a printed design that is protected by a transparent wear layer. The range consists of 96 references across a mix of vibrant designs, solid colours, woods, minerals, natural materials and textile effects.


Features and benefits:

  • Protecsol® 2 surface treatment which eliminates the need for waxing.
  • Easy and cost-effective maintenance, with less water and detergent use.
  • Durable construction – suitable for high traffic applications.
  • Type Binder classification I.
  • R10 slip resistance rating.
  • Highly flexible, easy to install and weld.
  • Compatible with the Gerflor Clean Corner system.
  • Wide range of designs and colours (96 references across 9 design themes).
  • Includes references that are accredited by the Dementia Services Development Centre (DSDC).
  • Contemporary matt finish.
  • 100% recyclable and contains 15% recycled content.
  • High level of indoor air quality - total volatile organic compounds (TVOC) after 28 days: <10 µg/m³.
  • Also available as Taralay Impression Acoustic, Taralay Impression HOP Compact (loose lay) and Taralay Impression HOP Acoustic (loose lay) - all specified separately.
  • The Taralay Impression range can be customised using digital print technology. Contact manufacturer for details.


Installation and maintenance:

Should be installed in accordance with the BS 8203: 2017 Code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available. Can be installed with the patented Clean Corner System for ensured hygiene.

General information

Color

Other

Guidance for specification option:

Please see specification data for options.

Finish

Matt

Material

Vinyl

Shape

Rectangle

Length

25000 mm

Width

2000 mm

Height

2.0 mm

Warranty description

12 year

Uniclass

Pr_35_57_71_67 Polyvinyl chloride (PVC) sheetsPrimary

CAWS

M50/20 Sheeting

M50/150 Sheeting

Product range

Sheeting / Heterogeneous Compact Flooring

Specification data - Polyvinyl chloride (PVC) sheets

Standard

To EN ISO 10582.

Use class

To BS EN ISO 10874, class 34–43.

Guidance for specification option:

Commercial, very heavy – Light industrial, heavy.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Guidance for specification option:

To EN 16165 app B.

Recycled content

15%.

Width

2000 mm.

Thickness

2.0 mm.

Colour and pattern

CHARME KRAFT.

Wear layer

0.70 mm.

Guidance for specification option:

Thickness of wear layer.

Weight

2635 g/m².

Static electricity

<2 kV.

Guidance for specification option:

BS EN 1815 static electricity electrical propensity.

Fire classification (EN 13501-1)

Bfl-s1.

ThermalConductivity

0.25 W/m·K.

Guidance for specification option:

To EN ISO 10456.

Surface treatment

Protecsol® 2.

Accessories

Co-ordinating weld rods.

Wear group

T.

Binder

Type I.

Guidance for specification option:

Binder content to ISO 10582.

Impact sound reduction (to EN-ISO 717-2)

8 dB.

VOC emissions

<10 µg/m³.

Guidance for specification option:

TVOC after 28 days (to ISO 16000-6).

Residual indentation (to EN-ISO 24343-1)

Average measured value ≈ 0.03 mm.

Guidance for specification option:

Requirement ≤ 0.10 mm.

Light reflectance value (LRV)/ Colour

26.9.

Length

25 m.

Sustainability data

Contains Red List materials

No

Country of product manufacture

France

Material

Vinyl

Recyclability

100%

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

15 %
