Taraflex® Evolution – Sheet - Sports flooring

Verified by manufacturer 6 months ago

Gerflor Flooring UK Limited Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

Taraflex® Evolution is a point elastic vinyl sheet sports floor covering, suited to all levels and all sports and suitable for non-sport usage that may occur in a sports area.

Jump to:
BIM object icon
+44 (0)3332 412901 Website

Application

Suitable for a variety of sports and leisure activities.

Description

Taraflex® Evolution is a multi-purpose vinyl sheet sports floor covering consisting of a D-Max™ surface - Gerflor’s own complex made up of calendered polyvinyl chloride (PVC) sheets reinforced with a fibre glass grid for high durability and outstanding dimensional stability. It is backed with double density CXP HD™ closed cell foam for performance and safety.


Features and benefits:

  • P1 shock absorption category sports floor (EN 14808).
  • Impact Protection Index (IPI) of 76% for medium protection to users falling, sliding or diving on the floor.
  • Triple Action Protecsol® surface treatment for easy maintenance, friction burn protection and ‘intelligent’ sliding coefficient.
  • Available in 20 solid colours and wood designs as standard. A further 127 solid colour options and bespoke digitally printed options are available, subject to a minimum order quantity.
  • Available as a Dry-Tex™ system as a solution for damp subfloors, suitable for new builds (specified separately).
  • Combine with Isolsport for damp subfloors and overlay refurbishment of some floor types (specified separately).
  • 100% recyclable.
  • As used by many leading International Sport Federations –contact manufacturer for full list.


Installation and maintenance:

  • Should be installed in accordance with the BS 8203:2017 Code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available; consult manufacturer for details.
  • Combine with Isolsport for damp subfloors and overlay refurbishment of some floor types (specified separately).

General information

Color

Other

Pleas see specification data for options.

Finish

Matt

Material

Vinyl

Length

26500 mm

Maximum roll length.

Width

1500 mm

Height

7.5 mm

WarrantyDescription

12 year

Uniclass

Pr_35_57_71_32 Foam-backed polyvinyl chloride (PVC) sheetsPrimary

CAWS

M50/150 Sheeting

M50/20 Sheeting

Product range

Sheeting / Vinyl Sports Flooring
Sports Flooring / Vinyl Sports Flooring

Specification data - Foam-backed polyvinyl chloride (PVC) sheets

Standard

To EN 14904.

Width

1500 mm.

Thickness

7.5 mm.

Colour and pattern

6350 Light Cherry.

5742 Wood Oak.

6381 Maple Design.

6830 Black.

6570 Mint Green.

6557 Forest.

6559 Spring.

6347 Beige.

6873 Anthracite.

3764 Taupe.

6758 Silver Gray.

6445 Lagoon.

6430 Blue.

2404 London Light Blue.

6431 Teal.

6211 Gold.

6038 Terracotta.

6159 Pink.

6180 Red.

6146 Coral.

Bespoke colour.

Further solid colour references are available with a minimum order quantity, contact manufacturer for details.

My Taraflex® bespoke digital print service.

Contact manufacturer for details and insert requirements.

Weight

4.7 kg/m².

Abrasion resistance

≤350 mg.

To BS EN ISO 5470-1

Fire classification (EN 13501-1)

Cfl-s1.

Impact resistance

≥8 N/m.

To BS EN 1517

Resistance to indentation (minimum)

≤0.5 mm.

To BS EN 1516

Product Reference

Taraflex® Evolution – Sheet

Accessories

None.

Co-ordinating weld rods.

My Taraflex® bespoke digital print service.

Contact manufacturer for details and insert requirements.

Ball rebound

≥90 %

Ball bounce to BS EN 12235.

Sliding properties

80–110.

To BS EN 13036-4 Sliding coefficient.

Deformation capability

≤ 2.0 mm.

To BS EN 14809 Vertical deformation.

Shock absorption

P1

To EN 14808.

Impact protection (minimum)

76 %

Impact Protection Index (IPI) to AC-P90-205.

Surface treatment

Triple Action Protecsol

Environmental information

Recyclability

100%
