SW60 TruEnergy Window - Residential Window System
Verified by manufacturer 3 days ago
Side Hung
Side Hung
Thermally efficient and high security aluminium windows.
Application
Suitable for use in residential and light commercial environments, including:
- Housing
- Retail.
- Sports and leisure facilities.
- Medical facilities.
- Educational buildings.
Description
The SW60 window system has been designed to offer great levels of performance - thermal efficiency, high security and slim sightlines. The SW60 system also offers versatility allowing the end user to choose a window with a stepped or flush appearance. This choice is made possible by a simple frame adjustment and with a wide range of frame options available the SW60 is well placed to satisfy the needs of an ever changing marketplace.
Features and benefits:
- Flush, stepped and heritage options.
- Slim profiles offer reduced sightlines.
- Internal and external glaze options.
- French casement available.
- Handle fixing block feature for easier fabrication.
- Extensive range of cills.
- PAS 24 security.
- Secured by Design.
- TW70 and SW60 profiles are available for use across both systems.
- Document L compliant system.
General information
Color | Clear Beige Black Blue Bronze |
Finish | Powder-coated |
Material | Aluminium |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | L10/25 Aluminium windows L10/330 Aluminium windows |
SKU Code | SW60 |
Specification data - Aluminium window units
Classification data | |
Dimensions and configurations | Side hung. Manufacturer guidanceInsert size requirements.
|
Product performance | |
Safety | |
Security level | To PAS 24. Secured by Design certification. |
Environmental | |
Background ventilation | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Thermal | |
Whole window U-value | Manufacturer guidanceU-Value of 1.2 W/m²K (0.7 centre pane value with infills). U value of 1.5 W/m²K (1.0 centre pane value with infills). Consult manufacturer for details and insert requirements. |
Frame | |
Profile | Flush. Stepped. Heritage. Manufacturer guidanceFrame depth: 70 mm. |
Finish as delivered | |
Coating | Powder-coated. |
Colour | Manufacturer guidanceInsert requirements.
|
Film thickness (minimum) | Coating applicator to determine. |
Ventilator | Manufacturer guidanceConsult manufacturer for details and insert requirements or omit. |
Glazing or infill | |
Requirements | Manufacturer guidanceInsert requirements.
|
Hardware | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Operation | |
Type | Manual. |
Electrical supply | None, manual. |
Fixing features | Manufacturer guidanceConsult manufacturer for details and insert requirements. |
Sustainability data
Material | Aluminium |
