Superglass Superwall 34 Cavity Wall Batt - Cavity wall insulation

Name: Superglass Superwall 34 Cavity Wall Batt - Cavity wall insulation
Brand: Superglass Insulation Ltd
SKU: 22LGnPpHRB3RKeDHiwBorg

Verified by manufacturer 10 days ago

Superwall 34 Cavity Batt - 75 mm

Superglass Insulation Ltd

Third party certifications:

EPD
Certificate type
ISO 9001 Quality Management
Certificate type
BBA Agrément Certificate
Certificate type
UK Conformity Assessed (UKCA)
Certificate type
CE Marking
Certificate type
BS EN 13501-1
Certificate type
DoP
Certificate type
CCPI Product
Certificate type

Superglass Superwall 34 is a British Board of Agrément (BBA) approved, non-combustible glass mineral wool insulation cavity wall batt.

Jump to:

+44 (0)808 1645 134 Website

Application

Superglass Superwall 34 is designed to provide thermal insulation in full or partial fill in new external masonry cavity walls, up to 25 metres in height for full fill and without restriction for partial fill in buildings of a domestic and non-domestic nature. Additional requirements apply for buildings above 12 metres in height for full fill and above 25 metres in height for partial fill, please refer to the product BBA certificate for more information.

Superwall 34 is BBA approved for use in all UK exposure zones (subject to conditions detailed in the BBA Certificate)

Description

Superglass Superwall 34 is a British Board of Agrément (BBA) approved, non-combustible glass mineral wool insulation cavity wall batt, manufactured with a water-repellent additive to resist moisture ingress. The flexible batt is supplied at 455mm wide to allow easy installation between standard vertical wall tie spacings, reducing the need for on-site cutting and waste.

Thermal Conductivity:

Declared thermal conductivity (lambda (λ) value) of 0.034W/mK.

Fire Classification:

Deemed non-combustible with a fire classification of Euroclass A1 (the highest possible rating) when tested to BS EN 13501-1 Reaction to Fire.

Vapour Resistivity

The product has a nominal vapour resistivity of 5 MN·s/g·m.

Environmental credentials.

Manufactured in accordance with ISO 14001 - Environmental Management Systems (EMS). Certificate number: EMS 646508.
Contains no ozone-depleting substances or greenhouse gases. For more information, please refer to the Environmental Product Declaration (EPD).
Made from up to 84% recycled glass.
Generic BRE Green Guide Rating of A+.

CCPI (Code for Construction Product Information)

Holds a CCPI Verification Mark. Certificate number: 005800103/1026.

Standards and Approvals.

BS EN 13162:2012(+A1:2015) Thermal insulation products for buildings - Factory made mineral wool (MW) products.
BS EN 13172: 2012 Thermal insulation products – Evaluation of conformity.
BS EN ISO 9001 - Quality Management Systems (QMS). Certificate number: FM 02264.

Certification:

UKCA certified to BS EN 13162:2012+A1:2015. Certificate number: 0086 CPR 469699.
CE marked to BS EN 13162:2012+A1:2015. Certificate number: 0751-CPR-399.0-01.
BBA certified for full and partial fill applications. Certificate number: 89/2231.

Below DPC level.

The product may be used in situations where it bridges the DPC in

walls; dampness from the ground will not pass through to the inner leaf provided the wall is detailed in accordance with the requirements and provisions of the national Building Regulations.

Water Resistance

Constructions incorporating the product and built in accordance with the Standards listed in section 4.4 of BBA Certificate 89/2231 Product Sheet 5, will resist the transfer of precipitation to the inner leaf and satisfy the national Building Regulations.

General information

Color	Yellow
Material	Glass mineral wool Glass Fibre
Shape	Rectangle
Length	1200 mm
Height	75 mm 100 mm 125 mm 150 mm

Uniclass	Pr_25_57_06_56 Mineral wool slab insulationPrimary
CAWS	F30/10 Full fill cavity insulation F30/12 Partial fill cavity insulation F30/150 Full fill cavity insulation F30/155 Partial fill cavity insulation

Product range	External Cavity Wall Insulation Glass Mineral Wool Insulation

Specification data - Mineral wool slab insulation

Standard	To BS EN 13162. Guidance for specification option: Manufactured in accordance with BS EN 13162:2012(+A1:2015) Thermal insulation products for buildings. Factory made mineral wool (MW) products. BS EN 13172:2012 Thermal insulation products. Evaluation of conformity BS EN ISO 9001:2015 Quality Management Systems (QMS). Water resistance construction incorporating the product and built in accordance with the Standards listed in section 4.4 of BBA Certificate 89/2231 Product Sheet 3, will resist the transfer of precipitation to the inner leaf and satisfy the national Building Regulations.
Thickness	75 mm.
Thermal conductivity (maximum)	0.034 W/m·K.
Fire performance	Reaction to fire classification of A1, as defined in BS EN 13501-1. Guidance for specification option: All Superglass products are deemed non-combustible and have a fire classification of A1 when tested to BS EN 13501-1 reaction to fire.
Recycled content	Up to 84%. Guidance for specification option: Manufactured from up to 84% recycled glass which would otherwise go to landfill.

R-Value	2.20 m²K/W.
Length	1200 mm.
Form	Glass mineral wool batt.
Width (nominal)	455 mm. Guidance for specification option: Length: 1200 mm.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Material	Glass mineral wool Glass Fibre
Manufacturing plant location	Stirling FK7 7QQ, UK
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	1.35 kg CO₂ eq/kg Manufacturer guidance Please see product EPD.
Recycled content As defined in clause 7.8 of BS EN ISO 14021	84 % Guidance for specification option: Manufactured from up to 84% recycled glass which would otherwise go to landfill.
Expected Life	Lifetime
