Ecophon Super G Plus A Acoustic Ceiling - Acoustic panels

Name: Ecophon Super G Plus A Acoustic Ceiling - Acoustic panels
Brand: Saint-Gobain Ecophon
SKU: xp6TQEEexsxmfMkaZHKTTe

Verified by manufacturer 11 days ago

M527 – Suspended ceiling

Saint-Gobain Ecophon

Product certifications:

Indoor Air Comfort – Eurofins
Certificate type
EPD
Certificate type
EPD
Certificate type
Cradle to Cradle Certified
Certificate type
Cradle to Cradle Certified
Certificate type
EPD
Certificate type
ISO 14021:2016
Certificate type
European Technical Approvals
Certificate type

Exposed grid system with non-demountable tiles, for use where there is risk of high mechanical impact.

Jump to:

+44 (0)1256 855208 Website

Application

For use where there is some risk of high mechanical impact.

Description

Super G Plus A consists of Super G Plus tiles and Connect grid. Super G Plus A has a robust galvanized grid system, consisting of recessed profiles mounted directly onto the soffit or on a rigid, suspended sub-grid.

Features and benefits:

The tiles are manufactured from high-density glass wool.
The visible surface is a strong glass fibre fabric, and the back of the tile is covered with glass tissue. The edges are primed.
The tiles are not demountable.

General information

Color	White
Finish	Other Guidance for specification option: Acoustic textile
Material	High-density glass wool Guidance for specification option: All Ecophon products are glass wool made from a recycled glass with a high recycled content (High-density glass wool).
Shape	Rectangle
Length	1200 mm
Width	600 mm
Height	40 mm
Warranty description	Ten year Guidance for specification option: All Ecophon installations can be warranted for ten years. 50 year Guidance for specification option: Design life.

Uniclass	Ss_30_25_22_51 Modular suspended ceiling systemsPrimary
CAWS	K40/105 Suspended ceiling system K40/10 Unit/ modular suspended ceilings K45/13 Unit suspended ceiling system alterations K45/160 Board-suspended ceiling system alterations K45/12 Existing suspended ceiling system K45/130 Unit-suspended ceiling system alterations K40/265 Infill units K45/120 Existing suspended ceiling system K40/115 Unit/ modular suspended ceiling system

SKU Code	Super G Plus A Acoustic ceiling

Specification data - Modular suspended ceiling systems

Classification data
Ceiling support	Connect™ Recessed profile.
Support fasteners	Rigid hangers and sub grid. Guidance for specification option: 10 kg/m² system weight (approximate), 305 mm overall system depth.
Ceiling units	Super G Plus A high-density glass wool tiles.
Barriers in ceiling void	-
Fire barriers	- Manufacturer guidance Insert requirements or omit.
Acoustic barriers	- Manufacturer guidance Insert requirements or omit.
Plenum barriers	- Manufacturer guidance Insert requirements or omit.
Samples required	- Manufacturer guidance Upon request.
System accessories	Grid and Recessed profile. Guidance for specification option: Insert requirements; consult manufacturer for information.
Installation	M527 – Suspended ceiling.
Maximum live load	20 N. Guidance for specification option: Minimum load bearing capacity: 220 N.
Reaction to fire	To EN 13501-1, A2-s1,d0.
Size (length x width)	1200 x 600 mm.
Thickness	40 mm.
Grid colour	White. Guidance for specification option: Nearest NCS: S 1002-Y. Light reflectance: 78%. Manufacturer guidance Consult manufacturer and insert requirements.
Trim	Connect™ Channel.
Constant humidity resistance	To EN 13964:2014, Class C, relative humidity 95% and 30°C.
Impact resistance	To EN 13964, Class 1A.
Indoor climate	Eurofins Indoor Air Comfort®: IAC Gold. French VOC: A+.
Standard	CE marked according to the European harmonized standard EN 13964:2014.
Cleaning	The ceiling system can withstand daily dusting and vacuum cleaning, and weekly wet cleaning.

Sustainability data

Contains Red List materials	No
Country of material origin	Sweden
Country of product manufacture	Sweden
Material	High-density glass wool Guidance for specification option: All Ecophon products are glass wool made from a recycled glass with a high recycled content (High-density glass wool).
A1–A3 ('Production stage')	Embodied carbon as defined in BS EN 15804
Normalized unit
Declared unit	7.73 kg CO₂ eq/m² Certified Guidance for specification option: Life-cycle stages A1 to C4 from EPD, in conformity with ISO 14025 / EN 15804. See Environmental Product Declaration Certificate.
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	57 %
Expected Life	50 year
