SunGuard® High Performance - Amber 41/29
Application

  • Curtain walling.
  • Window systems.
  • Spandrels.
  • Conservatory walls and roofs.

Description

Produced on ExtraClear float glass, SunGuard® High Performance is manufactured by sputtering extremely thin, multiple layers of metal and metal oxides onto a glass substrate, based on the patented Silacoat® process. The dynamic performance of the various coatings on clear substrates covers the spectrum of energy-efficient, colourful design applications. SunGuard® High Performance glass delivers high visible light transmission and moderate reflectivity together with maximum energy savings that meet or exceed energy regulation requirements. The range can be further processed as follows:

Further processing:

  • Cut to size.
  • Toughening.
  • Heat soaking.
  • Heat strengthening.
  • Laminating.
  • Drilling.
  • Notching.
  • Bending.
  • Edgeworking.
  • CNC shaping.
  • Screen-printing.
  • Manufacture into suitable double or triple glass insulating units.

Benefits:

  • Smart: Spectrally selective; transmits visible light and reflects solar radiation for reduced solar heat gain.
  • Multifunctional: Solar control and thermal insulation in one coating designed to provide maximum flexibility. No need to use a Low E inner pane with this product.
  • Durable: Can be tempered and curved. Compatible with most glazing materials. Extended shelf life combined with short lead time. May be laminated or silk screen printed.
  • Valuable: Cost efficient in both winter (thermal insulation) and summer (solar heat rejection) for an outstanding continuous return on investment.
  • Helps to control the energy balance in buildings.
  • Controls glare from the sun.
  • Restricts solar gain, increasing the useable areas inside buildings.

Applications:

  • Curtain walling.
  • Window systems.
  • Spandrels.
  • Conservatory walls and roofs.

Standards:

Guardian Europe has ISO 9001 accreditation for the manufacture of float glass at all of its European based float glass plants. Guardian low-emissivity coated glass complies with the requirements of EN 1096-4: 'Glass in Building – Coated Glass'. Guardian also has ISO 14001 Environmental Management System standard.

General information

Features

Uniform appearance and high colour rendering, low solar energy absorption

Material

Float Glass

Uniclass 2015

Pr_25_71_33_88 Thermally toughened glass sheetsPrimary

CAWS

H10/10 Patent glazing

H10/115 Patent glazing

H11/110 Curtain walling

H13/115 Structural glass assembly

L40/210 Putty-fronted single-glazing

L40/230 Bead-fixed single-glazing

L40/250 Bead-fixed single-glazing

L40/260 Bead-fixed single-glazing

L40/310 Bead-fixed single-glazing

L40/330 Bead-fixed single-glazing

L40/350 Bead-fixed single-glazing

L40/370 Bead-fixed insulating glass units

L40/371 Bead-fixed insulating glass units

L40/372 Bead-fixed insulating glass units

L40/380 Bead-fixed insulating glass units

L40/381 Bead-fixed insulating glass units

L40/40 Putty-fronted single-glazing

L40/410 Single-glazing into grooves

L40/430 Single-glazing into grooves

L40/450 Single-glazing into grooves

L40/470 Zipper gasket glazing

L40/490 Single-sided gasket glazing

L40/50 Bead-fixed single-glazing

L40/530 Internal tape glazing

L40/55 Bead-fixed insulating glass units

L40/57 Bead-fixed insulating glass units

L40/58 Bead-fixed insulating glass units

L40/90 Internal tape glazing

Specification data - Thermally toughened glass sheets

Product Reference

SunGuard® High Performance

Type

-

Glass

ExtraClear Float

ExtraClear LamiGlass®

Coating

Amber 41/29 (Typical 6-16-4 double glazing performance: 1.1 U-value, 41% light transmission, 29% solar factor)

Bright Green 40/29 (Typical 6-16-4 double glazing performance: 1.1 U-value, 40% light transmission, 29% solar factor)

Bronze 40/27 (Typical 6-16-4 double glazing performance: 1.1 U-value, 40% light transmission, 27% solar factor)

Light Blue 62/52 (Typical 6-16-4 double glazing performance: 1.5 U-value, 62% light transmission, 52% solar factor)

Neutral 41/33 (Typical 6-16-4 double glazing performance: 1.4 U-value, 41% light transmission, 33% solar factor)

Neutral 50/32 (Typical 6-16-4 double glazing performance: 1.1 U-value, 50% light transmission, 32% solar factor)

Neutral 60/40 (Typical 6-16-4 double glazing performance: 1.1 U-value, 60% light transmission, 40% solar factor)

Royal Blue 41/29 (Typical 6-16-4 double glazing performance: 1.1 U-value, 41% light transmission, 29% solar factor)

Silver 35/26 (Typical 6-16-4 double glazing performance: 1.2 U-value, 35% light transmission, 26% solar factor)

Silver 43/31 (Typical 6-16-4 double glazing performance: 1.2 U-value, 43% light transmission, 31% solar factor)

Thickness

4 mm

6 mm

8 mm

10 mm

12 mm

On special request.

Standard product features

Size:

- Manufacturer's standard (other sizes available):

  • Jumbo: 3210 x 6000 mm.
  • Split: 3210 x 2250–2550 mm.

Product Options

Thickness:

Properties shown are for ExtraClear Float only. ExtraClear LamiGlass® is also available for SunGuard® High Performance – consult manufacturer for stability and availability.

Digital objects
Platform Compatible Version Certified to
IFC

IFC2X3

3

1.3
Revit

Revit 2016

4

2.0
Download now from NBS National BIM Library
