SunGuard® Solar - Grey 20


  • Curtain walling.
  • Window systems.
  • Spandrels.
  • Conservatory walls and roofs.


Produced on ExtraClear Float glass, SunGuard® Solar and High Durable coated glass is designed to reduce unwanted solar gain, available in a range of contemporary colours. The coating reflects heat from the sun, making the internal building environment comfortable. SunGuard Solar and High Durable glass is manufactured by applying multiple layers onto a glass substrate, based on the patented Silacoat® process. The SunGuard® Solar and High Durable ranges may be complemented by the ClimaGuard® low-emissivity range in providing a choice of solar heat gain and thermal insulation levels allowing you to satisfy all building energy standards. The HD products can be used monolithically without being fabricated into insulating glass units, when used in these applications the coating should be on surface 2 facings away from the exposed front of the glass.

Further processing:

  • Cut to size.
  • Toughening.
  • Heat soaking.
  • Heat strengthened.
  • Laminated.
  • Drilled.
  • Notching.
  • Bending.
  • Edgeworking.
  • CNC shaping.
  • Screen-printing.
  • Manufactured into suitable double or triple glass insulating units.
  • HD Products can be used monolithically (Check with manufacturer for approved applications)
  • Where HD products are used monolithically they should be installed on Surface 2


  • Effective solar barrier: extremely low solar energy transmission.
  • Attractive: range of colours available; natural appearance when viewed in reflection or transmission.
  • Durable: can be tempered and bent; extended shelf life combined with short lead time.
  • Helps to control the energy balance in buildings.
  • Controls glare from the sun.
  • Restricts solar gain, increasing useable areas inside buildings.
  • May be laminated or silk screen printed.


  • Curtain walling.
  • Window systems.
  • Spandrels.
  • Conservatory walls and roofs.


Guardian Europe has ISO 9001 accreditation for the manufacture of float glass at all of its European based float glass plants. Guardian Low-emissivity coated glass complies with the requirements of EN 1096-4: ‘Glass in Building – Coated Glass’. Guardian also has ISO 14001 Environmental Management System standard.

General information


Uniform colour in transmission and reflection, excellent chemical and mechanical life


Float Glass

Uniclass 2015

Pr_25_71_33_88 Thermally toughened glass sheetsPrimary


H10/10 Patent glazing

H10/115 Patent glazing

H11/110 Curtain walling

H13/115 Structural glass assembly

L40/210 Putty-fronted single-glazing

L40/230 Bead-fixed single-glazing

L40/250 Bead-fixed single-glazing

L40/260 Bead-fixed single-glazing

L40/310 Bead-fixed single-glazing

L40/330 Bead-fixed single-glazing

L40/350 Bead-fixed single-glazing

L40/370 Bead-fixed insulating glass units

L40/371 Bead-fixed insulating glass units

L40/372 Bead-fixed insulating glass units

L40/380 Bead-fixed insulating glass units

L40/381 Bead-fixed insulating glass units

L40/40 Putty-fronted single-glazing

L40/410 Single-glazing into grooves

L40/430 Single-glazing into grooves

L40/450 Single-glazing into grooves

L40/470 Zipper gasket glazing

L40/490 Single-sided gasket glazing

L40/50 Bead-fixed single-glazing

L40/530 Internal tape glazing

L40/55 Bead-fixed insulating glass units

L40/57 Bead-fixed insulating glass units

L40/58 Bead-fixed insulating glass units

L40/90 Internal tape glazing

Specification data - Thermally toughened glass sheets

Product Reference

SunGuard® Solar




ExtraClear Float

ExtraClear LamiGlass


Neutral 67 (Typical 6-16-4 double glazing performance: 53% light transmission, 40% solar factor)

Light Blue 52 (Typical 6-16-4 double glazing performance: 41% light transmission, 31% solar factor)

Silver Grey 32 (Typical 6-16-4 double glazing performance: 26% light transmission, 21% solar factor)

Royal Blue 20 (Typical 6-16-4 double glazing performance: 18% light transmission, 16% solar factor)

Silver 20 (Typical 6-16-4 double glazing performance: 17% light transmission, 15% solar factor)

Bronze 20 (Typical 6-16-4 double glazing performance: 17% light transmission, 14% solar factor)

Gold 20 (Typical 6-16-4 double glazing performance: 18% light transmission, 16% solar factor)

Silver 08 (Typical 6-16-4 double glazing performance: 7% light transmission, 8% solar factor)

HD Light Blue 52

HD Neutral 67

HD Royal Blue 20

HD Silver 20

HD Silver 70

HD Silver Grey 32


4 mm

6 mm

8 mm

10 mm

12 mm

On special request.

Standard product features


Manufacturer's standard (other sizes available):

  • Jumbo: 3210 x 6000 mm.
  • Split: 3210 x 2250–2550 mm.

Product Options


Properties shown are for ExtraClear Float only. ExtraClear LamiGlass® is also available for SunGuard® Solar – consult manufacturer for stability and availability.

Digital objects

Platform Compatible Version Certified to




Revit 2016


Download now from NBS National BIM Library
