Structural Roof Decking
Description

A range of structural roof decking sheets of various profile depths manufactured in steel and aluminium capable of large spans and designed to support slab insulation and an external membrane to provide a flat insulated roof.

Features:

  • Wide range of profile depths and metal thicknesses.
  • Variety of finishes available as standard to one, or to special order both sides of the sheet.
  • Spans may be increased by using multi (three or more) spans rather than double spans, or by providing extended end laps.
  • Full load span information is available on the Tata Steel Panels and Profiles website or from the company technical department.
  • Can act in diaphragm to minimize bracing steelwork.
  • Available fully perforated or with perforated webs to provide acoustic absorption; non standard perforation patterns may be available.

Roof deck profile ranges:

  • Standard – Combines economy with aesthetics and structural performance.
  • Special – Further profile sections deemed 'specials' complementing the standard range. Maybe subject to minimum order requirements and extended lead times.

Fixing:

  • D32S, D35 – Main fixings at ridge and eaves at every pitch*, main fixings (intermediate) at every other pitch, side lap fixing is not essential.
  • D46, D60, D100+ – Main fixings at ridge and eaves at every pitch, main fixings (intermediate) at every pitch, side lap fixing at 450 mm centres, or as determined for diaphragm design.
  • D210 – Main fixings at ridge and eaves at every pitch, main fixings (intermediate) at every pitch, side lap fixing at 450 mm centres.

* Every other pitch is based on always starting with a fixing in the first pitch of every sheet, and a profile pitch of 200 mm or less.

General information
Features

Wide range of profile depths and metal thicknesses

Variety of finishes available as standard to one, or to special order both sides of the sheet

Spans may be increased by using multi (three or more) spans rather than double spans, or by providing extended end laps

Full load span information is available on the Tata Steel Panels and Profiles website or from the company technical department

Can act in diaphragm to minimize bracing steelwork

Available fully perforated or with perforated webs to provide acoustic absorption; non standard perforation patterns may be available

Uniclass 2015
Ss_30_40_65_50 Metal profiled sheet self-supporting roof covering systemsPrimary
Specification data - Metal profiled sheet self-supporting roof covering systems
Product Reference

Structural Roof Decking

Profile reference

D32S

Standard.

D35

Standard.

D46

Standard.

D46 Perf

Standard, perforated web with 10% open area.

D60

Standard.

D60 Perf

Standard, perforated web with13% open area.

D100

Standard.

D100 Perf

Standard, perforated web with 12% open area.

D159

Standard.

D159 Perf

Standard, perforated web with 8% open area.

D210

Standard.

D135

Special.

D135 Perf

Special, perforated web with 9.96% open area.

D153

Special.

D153 Perf

Special, perforated web with 11.3% open area.

D200

Special.

D200 Perf

Special, perforated web 11.17% open area.

Material -
Type

Aluminium

Standard roof deck profile range except D210.

Steel

Standard roof deck profile range and special roof deck profile range.

Gauge

0.7 mm

Standard roof deck profile range steel deck profile references, D32S, D35, D46, D46 Perf, D60, D60 Perf, D100 and D100 Perf.

0.9 mm

Standard roof deck profile range steel deck profile references, D32S, D35, D46, D46 Perf, D60, D60 Perf, D100 and D100 Perf.

1.2 mm

Standard roof deck profile range steel deck profile references, D32S, D35, D46, D46 Perf, D60, D60 Perf, D100 and D100 Perf.

1.25 mm

0.75 mm

0.88 mm

1.25 mm

1.5 mm

Special roof deck profile references, D200 and D200 Perf.

Finish -
Top

As standard

Soffit

Coated aluminium

ARS polyester or polyurethane resin reinforced with polyamide, available on 0.9 mm gauge aluminium deck profiles.

Colorcoat HPS200 Ultra

Standard roof deck profile range steel, 0.7 mm gauge deck profile references D46, D60, D100.

Galvanized

0.7, 0.9 and 1.2 gauge decks are available without any organic coatings. Standard roof deck profile range reference.

Lining enamel

Standard roof deck profile range steel, 0.7 mm, 0.9 mm, 1.2 mm gauge deck profile references D32S, D35, D46, D46 Perf, D60, D60 Perf, D100 and D100 Perf. Standard roof deck profile range steel, 1.25 mm gauge deck profile references D159 and D159 Perf.

Metallic coated aluminium

ARS polyester or polyurethane resin reinforced with polyamide, available on 0.9 mm gauge aluminium deck profiles.

Plain mill

Aluminium deck profiles.

Stucco embossed

0.9 mm gauge aluminium deck profiles.

Standard product features

Material:

All steel deck sheets are manufactured from galvanized steel.

Depth of deck:

The profile reference indicates the depth of the deck, e.g. D100 = 100 mm deep.

Cover width:

  • 600 mm – D210.
  • 700 mm – D100, D100 Perf.
  • 750 mm – D159, D159 Perf, D200, D200 Perf.
  • 800 mm – D60, D60 Perf.
  • 840 mm – D153, D153 Perf.
  • 900 mm – D35, D46, D46 Perf.
  • 930 mm – D135, D135 Perf.
  • 960 mm – D32S.

Tolerances:

All profiles comply with MCRMA requirements.

Length of deck:

Standard range deck sheets are available up to 12 m with the exception of D210 available in lengths up to 10 m. The special roof deck profile range is available in lengths up to 13.6 m.

Fire rating:

All non perforated deck sheets provide a fire rating of Class 1 to BS 476 -7 and Class O in accordance with current Building Regulations.

Product Options

Profile:

Profile references with 'Perf' appendages indicate that the deck has perforated webs to allow increased acoustic absorption. The percentage figure, where shown indicates the open area. Fully perforated decks and non standard perforation patterns are available to special order. In such cases Tata Steel Panels and Profiles should be consulted to establish suitability and to determine the structural properties of the deck.

Finish:

  • The standard finish for aluminium deck sheets is stucco embossed. Other finishes are available to special order and may be subjected to a minimum order quantity and extended lead times. Consult Tata Steel Panels and Profiles for details
  • Some standard roof deck profiles are available to special order with a coating on top and soffit sheet faces. Minimum order quantities may be required. Consult Tata Steel Panels and Profiles for details.

Soffit:

Consult Tata Steel Panels and Profiles for details of coating colours.
