Streetpod

Streetpod

Third party certifications:
  • QA Certificate

    QA Certificate

    Certificate type

  • Secured By Design

    Secured By Design

    Certificate type

Cyclepods Ltd

The Streetpod secure bike stand is a secure and stylish product that offers maximum bike protection for public location and open spaces, where bike security is a concern.

Jump to:
+44 (0)1959 546046 www.cyclepods.co.uk
Application

Suitable for use in various public locations and open spaces.

A solid level base is required for installation (e.g. concrete, large slabs with minimum 50 mm thickness). Consult manufacturer for further details.

Description

Highly secure cycle rack.

Features and benefits:

  • Provides a high level of bike protection.
  • The front wheel is housed within the security shield, which prohibits it from being removed.
  • Can secure the bike frame and both wheels with a single lock.
  • Solid steel locking hoop within reinforced steel hoop for added security.
  • Manufactured from recycled (Black only) and recyclable (all colours) MDPE.
  • Various design possibilities are available, including the addition of advertising and sponsorship graphics.
  • Channel is compatible for use with 99% of all standard European tyre widths.
  • No groundworks are required for installation.
  • Space-saving; each unit secures two bicycles within 700 mm - therefore the units are up to 30% smaller than traditional bike stands.
  • Graffiti and small scratches can be easily removed.
  • Secured by Design accredited.
  • Sold Secure Silver certified.

Application:

Suitable for use in various public locations and open spaces.

A solid level base is required for installation (e.g. concrete, large slabs with minimum 50 mm thickness). Consult manufacturer for further details.

General information

Color

Standard in Black (Recyclable) Red, Yellow, Royal Blue, Light Blue, Dark Green, Light Green, Grey, Stone effect and multicolour available (colours other than black are an additional cost)

Features

Space saving, secure, compatible

Finish

Dimpled effect

Material

Medium density polyethylene (MDPE)

Size

1610 x 1096 x 700 mm

WarrantyDescription

2 years

Uniclass 2015

Pr_40_30_21_65 Plastics cycle lockersPrimary

CAWS

Q50/210 Cycle stands

Q50/212 Cycle lockers

Q50/30 Street furniture

Specification data - Plastics cycle lockers Enhanced data

Product Reference

Streetpod

Configuration

Insert requirements.

Colour

Black

Standard (recyclable).

Dark green

Grey

Light blue

Light green

Red

Royal blue

Stone effect

Yellow

Securing loop

Galvanized steel

Standard.

Stainless steel

On request.

Fixings

Galvanized steel

Stainless steel

Graphics

Required

Advertising/ sponsorship can be incorporated. Consult manufacturer for details and insert requirements.

Not required

Shelter

Required

Consult manufacturer for details and insert requirements.

Not required

Weight

20 kg each

Fixing

M12/M14 monties, drilled to a depth of 100 mm (maximum), M14 sheer off nuts and resin. Securing loop arms will be fixed to the ground using ground anchors/ resin and five fixing bolts required (per Streetpod).

Standard product features

Colour:

Available in black (recyclable), dark green, grey, light blue, light green, red, royal blue, stone effect or yellow.

Material:

  • The body is made of medium density polyethylene (MDPE) and ground anchors are zinc plated.

Finish:

Dimpled effect.

Size:

Overall size (w x l x h): 700 x 1610 x 1096 mm, channel track is 65 mm wide, the pod wall is 7–9 mm thick and securing loop is 50 mm diameter x 3.2 mm thick The securing bar is 20 mm, solid.

Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
- 1 2.1
Download now from NBS National BIM Library
Third party certifications

Additional certifications:

  • Certified
