Sterndale Estate Fencing/ Modular Metal Railing

Verified by manufacturer 1 month ago

IAE

Estate fencing.

Jump to:
+44 (0)1782 339320 Website

Application

Suitable for:

  • Country estates.
  • Parkland.
  • Wildlife parks.
  • Farmland.

Description

Estate fencing supplied loose in 5000 mm lengths with wedges for fixing, and 1200 mm high as standard with a choice of ground fixing options.


Features and benefits:

  • Manufactured in accordance with BS 1722-8.
  • Low security level.
  • 1200 mm and 3600 mm wide single leaf gates and kissing gates are available from stock with other sizes available on a made to order basis.
  • Laser cut and robotically welded using modern folding and bending machines.

General information

Color

Silver

Finish

Galvanized

Material

Metal

Shape

Rectangle

Length

5000 mm

Height

1200 mm

Warranty description

Ten year

Uniclass

Ss_25_15_60_56 Metal post and rail barrier systemsPrimary

CAWS

Q40/30 Proprietary fencing

Q41/135 Proprietary protective barriers

Q41/130 Protective barriers

Q41/110 Pedestrian restraint systems in metal

Q40/430 Proprietary fencing

Q41/130 Protective barriers

Q41/110 Pedestrian restraint systems in metal

Specification data - Metal post and rail barrier systems

Standard

To BS 1722-8.

Posts

Joiner post x 1 (50 x 10 mm).
Inter post x 4 (40 x 10 mm).

Rails

Upper rail x 1 (25 x 6 mm).
Lower rail x 3 (25 x 6 mm).

Site applied finishes

Hot dip galvanized.

Guidance for specification option:

To BS EN ISO 1461.

System accessories

Not required.

1200 mm single leaf gate.

1200 mm kissing gate.

3600 mm single leaf gate.

3600 mm kissing gate.

Bespoke single leaf gate.

Guidance for specification option:

Made to order.

Bespoke kissing gate.

Guidance for specification option:

Made to order.

Ground fixings

Devils claw ground fixing.

Thrust plate ground fixing.

Centres

1000 mm.

Sustainability data

Contains Red List materials

No

Country of material origin

Turkey

Country of product manufacture

United Kingdom

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

0.16 kg CO₂ eq/unit

Recyclability

100
