Standard Unit Trip Rail
Verified by manufacturer 4 months ago
Type 002 - Flat Bar Posts
Type 002 - Flat Bar Posts
ISO 9001 Quality Management
Certificate type
Durable unit trip rails.
Application
Suitable for:
- Housing developments.
- Parks.
- Schools.
- Car parks.
Description
Standard Unit Trip Rail, also known as 'Knee Rail', is a discreet and affordable system for marking boundaries.
Features and benefits:
- Sleek and modern appearance.
- Two distinct design options: flat bar posts or circular posts.
- 1500 mm long unit panels.
- Quick and hassle-free installation.
- Manufactured from steel.
- Hollow sections S235JR.
- Solid sections S275JR.
- Supplied hot dipped galvanized.
- Optional polyester powder-coating to a RAL colour.
General information
Color | Black Green Grey Silver Blue |
Finish | Galvanized Powder-coated |
Material | Steel |
Shape | Rectangle |
Length | 1500 mm |
Height | 500 mm Bespoke |
Uniclass | |
CAWS | Q40/30 Proprietary fencing Q40/430 Proprietary fencing |
Specification data - Metal post and rail barrier systems
Posts | Steel 90 x 10 mm RSF flat posts. |
Post foundations | Ground fixed into concrete foundation.Manufacturer guidanceConsult manufacturer for details. |
Rails | Steel Ø60 mm CHS rails. |
Panel height | 500 mm. Bespoke. Guidance for specification option: Consult manufacturer and insert requirements. |
Panel length | 1500 mm. |
Finish | Hot dip galvanized to BS EN ISO 1461. |
Factory applied coating | Not required. Polyester powder-coated. Guidance for specification option:
|
Sustainability data
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Steel |
Third party certifications
ISO 9001 Quality Management
ISO 9001:2015 Quality Management System
Literature
Unit Trip Rail Data Sheet
Case studies
Reading University, London
