Standard Courtyard Gates
Verified by manufacturer 5 months ago
Cathedral gates
Cathedral gates
ISO 9001 Quality Management
Certificate type
Timber courtyard gates.
Application
For residential and commercial properties.
Description
Timber courtyard gates in a range of styles for providing a secure entrance to residential properties. 25-year guarantee on all timber and steel and 25-month automation guarantee.
Features and benefits:
- Incorporated integral adjustable hinges for maximum flexibility.
- Galvanized internal frame to eliminate twisting and warping.
- Both sides of the gate are clad the same - looks the same from the inside or the outside.
- Gates are supplied with galvanized metal posts as standard, additional polyester powder coating available or timber clad.
- Can be automated for added convenience and security.
- Range of automation options and access control devices available.
General information
Color | Other |
Finish | Pre-treated |
Material | Wood Steel |
Width | 3600 mm 3100 mm Bespoke |
Height | 1800 mm Bespoke |
Warranty description | 25 year Guidance for specification option: 25-year guarantee on all timber and steel. 25-month automation guarantee available where applicable. |
Uniclass | |
CAWS | Q40/45 Gates Q40/570 Gates |
Product range |
Specification data - Wood gates
Dimensions | |
Span | Manufacturer guidanceInsert requirements, 2500 mm minimum to maximum 4800 mm (double leaf gate set). |
Height | Manufacturer guidanceInsert requirements. Minimum 1800 mm to shoulder. |
Posts | Galvanized steel.Guidance for specification option: Standard. Powder-coated steel, black.Guidance for specification option: Additional cost applies. Timber clad galvanized steel.Not required.Guidance for specification option: Wall plates can be supplied to hang the gates on existing brickwork, providing it is in good condition. For new installations, the manufacturer recommends galvanized posts with extended hinges that the pier can be built around. Manufacturer guidanceHinge hooks are incorporated in the gate posts. |
Gate leaves | Tongue and groove effect boards, railing panels. |
Hardware | |
Hinges | Manufacturer's standard. |
Operating | Manual.Automatic. |
Finish as delivered | |
Worked finish | Planed. |
Treatment | Pressure treated. |
Applied finish | Manufacturer guidanceInsert requirements or omit. |
Accessories | None. Mortise lock (357400BM). Stop post (351900BM). Guidance for specification option: Stop post. Key pad. Hard-wire audio intercom. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | United Kingdom |
Third party certifications
ISO 9001 Quality Management
ISO 9001:2015 Quality Management System
