Stainless Steel Safety Mirror

S3030 - 300 x 300 mm

Clarke's Safety Mirrors Ltd Variant:

Highly polished safety mirrors manufactured from high grade 304 stainless steel. Virtually unbreakable, anti-vandal and hygienic. Used in a wide range of applications. Made to measure sizes available.

Jump to:
+44 (0)1952 605557 Website

Application

Suitable for applications for a wide range of applications. Stainless steel mirrors are often required in environments where good hygiene is needed or in areas where vandalism is likely. They can be fixed to any flat substrate. Typical environments include:

  • Schools.
  • Hospitals.
  • Prisons.
  • Food factories.
  • Public buildings.

Description

Stainless steel safety mirrors are typically used for anti-vandal environments. They are polished to an ultra bright finish to maximise reflection clarity and comply with all local and national health and safety legislation.


Features and benefits:

  • Virtually unbreakable.
  • Hygienic.
  • Made to measure service.
  • Available in 0.9 mm thick as standard, but can also be produced in 1.2 mm.
  • Manufactured from high-grade 304 (18/8) stainless steel. Can also be supplied in marine grade 316.
  • Free from tarnishing, discolouration, scratches and other defects visible in the designed viewing conditions.
  • Rounded corners and smooth, polished edges.
  • Customisable fixing options.

General information

Color

Silver

Finish

Smooth

Material

Stainless steel

Shape

Rectangle

Square

Circle

Length

Bespoke

300 mm

450 mm

800 mm

1200 mm

Show more

Width

Bespoke

300 mm

400 mm

450 mm

600 mm

Uniclass

Pr_40_30_53_46 Large mirrorsPrimary
Pr_40_30_53_06 Bathroom mirrors

Pr_25_71_53_82 Small mirrors

CAWS

N10/270 Mirrors

N13/438 Mirrors

Specification data - Large mirrors

Materials and standards

-

Materials

Stainless steel, grade 304.

As standard.

Stainless steel, grade 316.

Optional extra. Minimum order quantities apply. Contact manufacturer and insert requirements.

Dimensions

300 x 300 mm.

Thickness

0.9 mm.

Standard.

1.2 mm.

Optional extra.

Finish

Silvered.

Edges

-

Treatment

Smooth polished.

Profile

Rounded.

Rounded corners as standard.

Accessories

Not required.

Ligature resistant PVC frame.

Bonded to 6 mm PVC.

For uneven substrates.

Fixing options

Not required.

Screw holes and dome-head mirror screws (SSH04/ SSH06).

Screw holes and anti-tamper stainless steel fixing (SECS4/ SECS6).

Very high bond double-sided tape (TAP01).

Mirror adhesive (ADH01).

Radius

Corner radius.

4 mm.

Environmental information

Country of material origin

Taiwan

Country of product manufacture

United Kingdom

Recyclability

Widely recycled

Literature

CSM Stainless Steel Mirror O&M Manual

CSM Stainless Steel Mirror O&M Manual

CSM Stainless Steel Safety Mirror Specification Rev04

CSM Stainless Steel Safety Mirror Specification Rev04
