NBS Source
ST Flex Secure
Compare variants

Application

Suitable for sliding door installation, where additional intruder and vandalism protection is required.

Description

ST Flex Secure offers an high level of security and meets the increasing demand of facility operators for a system that combines the convenience of an automatic sliding door with additional intruder and vandalism protection. It offers improved security and is approved for application as a standard sliding door in emergency exits and escape routes.


Features and benefits:

  • Provides maximum intruder and vandalism protection according to VDS (Association of German Property Insurers) resistance class WK2.
  • In contrast to similar security systems, there are no visible barriers so that display windows remain transparent without any negative effect on their advertising space characteristics.
  • A continuous floor guide rail at the bottom of the door and an operator-integrated anti-tamper protection avoid the possibility that the door is levered out.
  • A four-point hook locking device at the main closing edge, which automatically locks in position and lateral profiles that interlock while the door is closed bring security to a high level.
  • The special burglary-protection glazing (made of sandwich glass) is adhered to the door profile with the aid of a special adhesive in order to make the door extremely resistant.
  • The door’s security features do not affect the operation of the door system while opening or closing – so that facility operators may use the door in the usual way.
  • The door may be equipped with any product from the comprehensive range of accessories.
  • If requested, the product may be fitted with DIN 18650 compliant safety equipment – depending on the prevailing structural conditions and risk assessment.
  • ES200 microprocessor controlled, modular designed automatic sliding door operator.
  • Tested and certified to 1 000 000 operation cycles.
  • Burglar resistance certified to WK2.
  • Class P4 A glazing as per EN 356.
  • Four point locking device.
  • Full width floor guide.
  • Masonry or steel concrete adjacent fixing.
  • Night/ bank facility for first and last entrance.
  • Five position mode switch (off, automatic, partial opening, exit only and hold open).
  • 150 mm high drive unit encased in purpose designed extruded aluminium profile.
  • Real time remote monitoring system.

General information

Color

Grey

Finish

Anodized

Silver anodized.

Powder-coated

Polyester powder coated.

Other

Aluminium profile coating.

Material

Steel

Aluminium

Shape

Rectangle

Uniclass

Pr_30_59_24_80 Sliding door and partition setsPrimary

CAWS

L20/520 Sliding doors

L20/490 Automatic doors

Product range

Automatics / Sliding Doors

Specification data - Sliding door and partition sets

Door leaves

-

Construction

Door leaves and fixed side screens constructed from single or double glazed burglary resistant toughened or laminated P4 A glazing in fine framed profiles.

Aluminum framed, single glazed, laminated glass.

Aluminum framed, double glazed, laminated glass.

Aluminium framed, single glazed, toughened glass.

Aluminium framed, double glazed, toughened glass.

Finish and colour

Aluminium profile coating.

Polyester powder coating.

Silver anodized.

Operation

Powered.

Hardware

DORMA Secure four point locking device – type 3 pivoting bolt lock with four swing bolts.

Activation

Jamb switch.

Slimline satin stainless steel, 115 x 45 mm.

Radar.

DORMA Prosecure Opti-Combi combined radar activation and threshold infrared safety sensor.

Via access control.

Link to access control (by others). A normally open volt free contact momentarily closed on receipt of a valid signal from the access control system is required.

Wall switch.

Hard wired or wireless wall switch actuation satin stainless steel, 150 x 150 mm.

Clear passage height

2100–3100 mm. Insert requirements.

Clear passage width

Insert requirements. 1000-2000 mm.

Panel weight

160 kg (maximum).

ST Flex Secure: 2 x 160 kg.

Real time remote monitoring system

Not required.

Required.

Safety devices

  • Self-regulating safety system monitoring all door movements including closing force.
  • Auto reverse function if the doors make contact with an obstruction during the closing cycle (infrared threshold safety sensor).
  • Emergency break glass.
  • Rear edge safety.
  • Full height frameless pocket screens constructed from 10 mm toughened safety glass and patch fittings.
  • 900 mm high all glass solid infill safety barriers.
  • DORMA Prosecure Opti Scan Rear Edge Presence Sensors reducing the door to 'Low Energy Speed' upon activation.

Door movement monitoring and closing force.

Auto reverse function.

Emergency break glass.

Rear edge safety.

Pocket screens.

Show more

Power failure

Monitored battery back-up system to automatically open the doors in the case of a power failure or upon a signal from the interfaced fire alarm system.

Digital objects

Platform Compatible Version Certified to
Revit
-

1

1

Download now from NBS National BIM Library
