Description

Designed to provide a door capable of being manufactured in single, double, inward or outward opening and utilizing low thresholds producing a variety of options to suit most applications.

A 51 mm thermally broken polyamide door system which achieves excellent performance in very challenging circumstances. Capable of accepting a variety of glazing options.

Construction:

Constructed with mitred and mechanically crimped or joined corners, with support chevrons and cleats to ensure accurate alignment. Integral transoms and mullions are fixed into the outer frames with screws or brackets. Joints are sealed against water ingress during assembly.

Opening door frames are inserted directly into the outer frames using face mounted hinges and hook locks.

General information
Size

As drawing

As schedule

Finish

Anodized

Insert colour requirements, 25 microns (minimum), satin or polished finish available.

Mill finish

Polyester powder coated

Insert colour requirements, 40 microns standard and 60 microns available for marine environments.

Material

Extruded aluminium: Aluminium alloy 6060 or 6063.T6 to BS EN 755-9

Polyamide thermal barriers are manufactured in accordance with PA66 GF25

Gaskets are manufactured in accordance with BS 3734

Uniclass 2015
Pr_30_59_24_52 Metal doorsetsPrimary
Specification data - Metal doorsets
Product Reference

SPW 300 Entrance Door System

Type

Double door, inward opening

Double door, outward opening

Single door, inward opening

Single door, outward opening

As drawing

Insert details.

Size

As drawing

As schedule

Finish

Anodized

Insert colour requirements, 25 microns (minimum), satin or polished finish available.

Mill finish

Polyester powder coated

Insert colour requirements, 40 microns standard and 60 microns available for marine environments.

Glazing -
Type

Insert requirements, 4 mm single to 28 mm double glazing available.

Glazing method

Inside glazed

As standard.

Outside glazed

Ironmongery/ Accessories

Manufacturer's standard

Standard product features

Typical size (w x h):

  • Single door: 1000 x 2400 mm.
  • Double door: 2000 x 2400 mm.

Material:

  • Extruded aluminium: Aluminium alloy 6060 or 6063.T6 to BS EN 755-9.
  • Polyamide thermal barriers are manufactured in accordance with PA66 GF25.
  • Gaskets are manufactured in accordance with BS 3734.

U-Value:

  • Single Open in: 2.12, Open out: 2.21 W/m²K.
  • Double Open in: 2.02, Open out: 2.10 W/m²K.

Performance:

Differing door configurations produce different ratings; consult Senior Architectural Systems for details.

Security:

Tested to BS 7950, security hardware required.

Product Options

Finish:

Polyester powder coated available in single or dual colour. Consult Senior Architectural Systems for availability of colours and samples.

Glazing:

  • Each pane of glass is individually inserted into a fully rebated and prepared opening.
  • Glazing beads with an internal option standard on inward opening and an option on outward opening doors.
  • Gasket seals to the inside create a bond between the glass and the main framing members.
