NBS Source
Sports Hall Door

Application

Suitable for installation in public facilities, private premises or local authority school environments.

Description

Sports hall door fitted with rebound boards which finish flush to adjacent walls to provide a projection-free face, eliminating sharp corners and reducing the risk of injury from uncontrolled collisions. Ironmongery is recessed to prevent accidental activation during a sporting event.


Features and benefits:

  • 50 mm thick door leaf.
  • 120 mm Zintec steel frames.
  • Adjustable standard frame cappings.
  • Anti-crush door frame reinforcement.
  • Multiple frame fixing straps.
  • Screw-in frame fixings.
  • Dog-bolt hinges.
  • Stainless steel leaf capping.
  • Factory fitted ironmongery.
  • Factory fitted seals.
  • Manual flush bolts to all inactive leaves.

General information

Material

Steel

Shape

Rectangular

Size

2780 x 3000 mm

Maximum size of structural opening.

Uniclass 2015

Pr_30_59_24_52 Metal doorsetsPrimary

CAWS

L20/480 Doorsets

L20/55 Doorsets

Product range

Doors

Specification data - Metal doorsets Enhanced data

Configuration

Single leaf.

Leaf and part leaf.

Double leaf.

Doorset size

2780 x 3000 mm.

Maximum opening size. Larger structural openings can be accommodated by the use of side panels and over panels. Consult manufacturer for more details.

Frame

-

Material

Zintec steel.

Door leaf

-

Thickness

50 mm.

Material

Steel.

Lippings

Lipped.

Rebated with security astragal.

Non-lipped.

Non-rebated meeting stiles.

Hardware

Touch-bar panic escape device.

Touch-bar panic escape device to BS EN 1125, mounted to prevent accidental activation as standard.

External door handle and lock.

External access for moving sports equipment in and out of the sports hall can be accommodated with an external lock and handle override for the door hardware.

Accessories

None.

Touch-bar panic escape device.

External lock and handle overide.

Optional.

Product Reference

Sports Hall Door

Colour

Consult manufacturer for available finishes and colours.
