Sphera SD

Name: Sphera SD
Brand: v9DFe6oJ1MnGdQqvvCxoBV
SKU: ebdphZV6RUkjZtLtEzVZEf

Forbo Flooring Systems UK Ltd

Homogeneous conductive sheet vinyl flooring.

Jump to:

+44 (0)800 093 5258 www.forbo-flooring.co.uk

Application

Specifically designed to control static discharges and particles in the most sensitive environments such as pharmaceutical, life sciences and healthcare facilities.

Description

Premium homogeneous vinyl sheet flooring with SMART top polyurethane (PUR) surface finish, offering high quality regardless of conditions.

Features and benefits:

Innovative product development and carefully controlled production processes ensure a solution with permanent conductive properties that comply with all electrostatic discharge (ESD) standards.

Retains high performance throughout the product’s lifetime regardless of environmental conditions (e.g., humidity levels).

Low emissions and phthalate-free manufacturing ensure that Sphera SD can contribute to a healthy indoor environment.

The SMART control surface treatment makes Sphera SD resistant to stains and scratches, for a durable and hygienic solution.

Conductive backing eliminates the need for conductive adhesive underneath the full sheet. It is only necessary to affix the copper strip, thus minimising installation errors and reducing costs.

Produced in a zero-waste environment, ensuring efficient and sustainable manufacturing.

Phthalate -free.

Application:

Specifically designed to control static discharges and particles in the most sensitive environments such as pharmaceutical, life sciences and healthcare facilities.

Adhesive:

641 Eurostar Special EL very low emission conductive adhesive for PVC for affixing copper strip.

640 Eurostar Special very low emission PVC adhesive.

General information

Finish	SMART control surface treatment
Material	Vinyl
Shape	Sheet
Size	2m wide
Uniclass 2015	Pr_35_57_71_67 Polyvinyl chloride (PVC) sheetsPrimary

Specification data - Polyvinyl chloride (PVC) sheets

Standard	EN ISO 10581, EN 14041
Use class	To EN ISO 10874: commercial: 34, very heavy; light industrial: 43, heavy
Slip potential	-
Slip resistance value	To BS EN 13893: DS: ≥0.30, to DIN 51130: R9
Pendulum test value	Dry >50
Width	2 m
Thickness	2 mm
Colour and pattern	Not required White SD550000 Light neutral grey SD 550003 Dark neutral grey SD 550005 Grey sky SD550007 Silver grey SD550008 Ivory SD550017 Mortar SD550018 Sand SD550023 Soft lilac SD550032 Amethyst SD550034 Water SD550036 China Blue SD550037 Olive SD550050 Yellow green SD550049
Reaction to fire (to BS EN 13501)	B(fl)-s1, G, NCS
Electrical resistance to IEC 61340-4-1, ESD STM7.1)	1 x 10^6 ≤ R ≤ 10^8 Ω
Lightfastness (to ISO 105-B02)	≥ 7
Dimensional stability (to BS EN ISO 23999)	≤0.4%
Thermal conductivity (to BS EN 12524)	0.25 W/m·K
Electrical resistance in combination with ESD control footwear (to IEC 61340-4-5, ESD STM97.1)	R ≤ 1 x 10^9 Ω
Resistance to chemicals (to EN ISO 26987)	Very good
Bacteria resistance (to EN846)	Does not support growth
Cleanroom particle emission (to ISO 14644-1)	ISO 6
Electrostatic (general requirements) (to IEC 61340-5-1)	Compliant
Electrical behaviour – static dissipative (to EN 1081)	≤ 1 x 10^9 Ω
Electrical insulation to ground (to DIN VDE 0100)	≥ 50 kΩ
Body voltage generation, in combination with ESD control footwear (to IEC 61340-4-5)	<50 V
Weight	2.9 kg/m²

Standard product features

Colour:
14 colours and designs available.
Feature:
Retains high performance throughout the product’s lifetime, regardless of environmental conditions (e.g., humidity levels).
Finish:
SMART control surface treatment.
Material:
Vinyl.
Shape:
Sheet.
Size:
2m wide
Warranty:
Ten years.
Recycled content:
0%.
Recyclability:
Via Forbo's Back to the Floor Scheme.
Embodied Carbon:
No EPD.
Country of origin:
Netherlands.

Environmental information

Embodied carbon	No EPD
Recyclability	Via Forbo's Back to the Floor Scheme
Recycled content	0%
